GenSwiss Micro Drills - Superior Micro Drills for Swiss Lathes

GenSwiss Micro-Drills are a cost effective solution for hard to find small diameter solid carbide micro drills & micro spotting tools. Swiss-style precision ensures maximum reliability, accuracy and finish results. When consistency of hole tolerance control is paramount, look to GenSwiss micro drills

Sizes range from as small as .1mm (.004") up to 3mm (.1181") and are precision ground and finished on shank diameters of 1 to 3mm making precision holding in standardized ER holders simple. These micro drills eliminate the need for expensive specialized micro collets.





Micro Drill Series

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3610 HiCo8 2-3 X Dia 120° 35° 2 h6 (+0.000 -0.006mm) No
3620 HiCo8 5 X Dia 120° 24° 2 h6 (+0.000 -0.006mm) No
3630 Solid Carbide 2-3 X Dia 120° 24° 2 h6 (+0.000 -0.006mm) No
3680 Solid Carbide 4-5 X Dia 120° 24° 2 h6 (+0.000 -0.006mm) No
3640 Solid Carbide 4-5 X Dia 120° 35° 2 h6 (+0.000 -0.006mm) No
3650 Solid Carbide 5-7 X Dia 140° 35° 2 h6 (+0.000 -0.006mm) No
3660 Solid Carbide 6-7 X Dia 140° 30° 2 h4 (+0,000 -0.003mm) No
3670 Solid Carbide 12 X Dia 140° 30° 2 h5 (+0,000 -0.004mm) No
3690 Solid Carbide 15 X Dia 140° 30° 2 h5 (+0,000 -0.004mm) Yes
3700 Solid Carbide 10 X Dia 120° None Half Round h5 (+0,000 -0.004mm) No
3710 Solid Carbide 4-6 X Dia 140° 30° 3 h5 (+0,000 -0.004mm) No
3720 Solid Carbide 4-6 X Dia 140° 30° 3 h5 (+0,000 -0.004mm) No

     Select A Series Below

3610

3610 Series - Center Cut - Pilot - Spot Drills

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3610 HiCo8 2-3 X Dia 120° 35° 2 h6 (+0.000 -0.006mm) No

Click Below To Expand

Drill Ø 0.2mm - 3.00mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length (mm) OAL (mm)
3610-000100 GD1-020-1.5-060-H 0.20 0.0079 1.5 0.6 25
3610-000101 GD1-025-1.5-080-H 0.25 0.0098 1.5 0.8 25
3610-000102 GD1-030-1.5-090-H 0.30 0.0118 1.5 0.9 25
3610-000103 GD1-035-1.5-100-H 0.35 0.0138 1.5 1.0 25
3610-000104 GD1-040-1.5-100-H 0.40 0.0157 1.5 1.0 25
3610-000105 GD1-045-1.5-120-H 0.45 0.0177 1.5 1.2 25
3610-000106 GD1-050-1.5-120-H 0.50 0.0197 1.5 1.2 25
3610-000107 GD1-055-1.5-140-H 0.55 0.0217 1.5 1.4 25
3610-000108 GD1-060-1.5-140-H 0.60 0.0236 1.5 1.4 25
3610-000109 GD1-065-1.5-170-H 0.65 0.0256 1.5 1.7 25
3610-000110 GD1-070-1.5-170-H 0.70 0.0276 1.5 1.7 25
3610-000111 GD1-075-1.5-180-H 0.75 0.0295 1.5 1.8 25
3610-000112 GD1-080-1.5-180-H 0.80 0.0315 1.5 1.8 25
3610-000113 GD1-085-1.5-180-H 0.85 0.0335 1.5 1.8 25
3610-000114 GD1-090-1.5-180-H 0.90 0.0354 1.5 1.8 25
3610-000115 GD1-095-1.5-200-H 0.95 0.0374 1.5 2.0 25
3610-000116 GD1-100-1.5-200-H 1.00 0.0394 1.5 2.0 25
3610-000117 GD1-105-1.5-230-H 1.05 0.0413 1.5 2.3 25
3610-000118 GD1-110-1.5-230-H 1.10 0.0433 1.5 2.3 25
3610-000119 GD1-115-1.5-230-H 1.15 0.0453 1.5 2.3 25
3610-000120 GD1-120-1.5-230-H 1.20 0.0472 1.5 2.3 25
3610-000121 GD1-125-1.5-270-H 1.25 0.0492 1.5 2.7 25
3610-000122 GD1-130-1.5-270-H 1.30 0.0512 1.5 2.7 25
3610-000123 GD1-135-1.5-270-H 1.35 0.0531 1.5 2.7 25
3610-000124 GD1-140-1.5-270-H 1.40 0.0551 1.5 2.7 25
3610-000125 GD1-145-1.5-270-H 1.45 0.0571 1.5 2.7 25
3610-000126 GD1-150-2.0-300-H 1.50 0.0591 2.0 3.0 25
3610-000127 GD1-160-2.0-300-H 1.60 0.063 2.0 3.0 25
3610-000128 GD1-170-2.0-330-H 1.70 0.0669 2.0 3.3 25
3610-000129 GD1-180-2.0-330-H 1.80 0.0709 2.0 3.3 25
3610-000130 GD1-190-2.0-300-H 1.90 0.0748 2.0 3.3 25
3610-000131 GD1-200-2.0-400-H 2.00 0.0787 2.0 4.0 25
3610-000132 GD1-210-2.5-400-H 2.10 0.0827 2.5 4.0 25
3610-000133 GD1-220-2.5-400-H 2.20 0.0866 2.5 4.0 25
3610-000134 GD1-230-2.5-460-H 2.30 0.0906 2.5 4.6 25
3610-000135 GD1-240-2.5-460-H 2.40 0.0945 2.5 4.6 25
3610-000136 GD1-250-2.5-460-H 2.50 0.0984 2.5 4.6 25
3610-000137 GD1-260-3.0-460-H 2.60 0.1024 3.0 4.6 25
3610-000138 GD1-270-3.0-530-H 2.70 0.1063 3.0 5.3 25
3610-000139 GD1-280-3.0-530-H 2.80 0.1102 3.0 5.3 25
3610-000140 GD1-290-3.0-530-H 2.90 0.1142 3.0 5.3 25
3610-000141 GD1-300-3.0-530-H 3.00 0.1181 3.0 5.3 25

3620

3620 Series

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3620 HiCo8 5 X Dia 120° 24° 2 h6 (+0.000 -0.006mm) No

Click Below To Expand

Drill Ø 0.1mm - 1.27mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3620-000100 GD2-010-1.0-070-H 0.10 0.0039 1.0 0.7 25
3620-000101 GD2-011-1.0-070-H 0.11 0.0043 1.0 0.7 25
3620-000102 GD2-012-1.0-070-H 0.12 0.0047 1.0 0.7 25
3620-000103 GD2-013-1.0-100-H 0.13 0.0051 1.0 1.0 25
3620-000104 GD2-014-1.0-100-H 0.14 0.0055 1.0 1.0 25
3620-000105 GD2-015-1.0-100-H 0.15 0.0059 1.0 1.0 25
3620-000106 GD2-016-1.0-140-H 0.16 0.0063 1.0 1.4 25
3620-000107 GD2-017-1.0-140-H 0.17 0.0067 1.0 1.4 25
3620-000108 GD2-018-1.0-140-H 0.18 0.0071 1.0 1.4 25
3620-000109 GD2-019-1.0-140-H 0.19 0.0075 1.0 1.4 25
3620-000110 GD2-020-1.0-180-H 0.20 0.0079 1.0 1.8 25
3620-000111 GD2-021-1.0-180-H 0.21 0.0083 1.0 1.8 25
3620-000112 GD2-022-1.0-180-H 0.22 0.0087 1.0 1.8 25
3620-000113 GD2-023-1.0-180-H 0.23 0.0091 1.0 1.8 25
3620-000114 GD2-024-1.0-180-H 0.24 0.0094 1.0 1.8 25
3620-000115 GD2-025-1.0-220-H 0.25 0.0098 1.0 2.2 25
3620-000116 GD2-026-1.0-220-H 0.26 0.0102 1.0 2.2 25
3620-000117 GD2-027-1.0-220-H 0.27 0.0106 1.0 2.2 25
3620-000118 GD2-028-1.0-220-H 0.28 0.011 1.0 2.2 25
3620-000119 GD2-029-1.0-220-H 0.29 0.0114 1.0 2.2 25
3620-000120 GD2-030-1.0-220-H 0.30 0.0118 1.0 2.2 25
3620-000121 GD2-031-1.0-280-H 0.31 0.0122 1.0 2.8 25
3620-000122 GD2-032-1.0-280-H 0.32 0.0126 1.0 2.8 25
3620-000123 GD2-033-1.0-280-H 0.33 0.013 1.0 2.8 25
3620-000124 GD2-034-1.0-280-H 0.34 0.0134 1.0 2.8 25
3620-000125 GD2-035-1.0-280-H 0.35 0.0138 1.0 2.8 25
3620-000126 GD2-036-1.0-280-H 0.36 0.0142 1.0 2.8 25
3620-000127 GD2-037-1.0-280-H 0.37 0.0146 1.0 2.8 25
3620-000128 GD2-038-1.0-280-H 0.38 0.015 1.0 2.8 25
3620-000129 GD2-039-1.0-280-H 0.39 0.0154 1.0 2.8 25
3620-000130 GD2-040-1.0-320-H 0.40 0.0157 1.0 3.2 25
3620-000131 GD2-041-1.0-320-H 0.41 0.0161 1.0 3.2 25
3620-000132 GD2-042-1.0-320-H 0.42 0.0165 1.0 3.2 25
3620-000133 GD2-043-1.0-320-H 0.43 0.0169 1.0 3.2 25
3620-000134 GD2-044-1.0-320-H 0.44 0.0173 1.0 3.2 25
3620-000135 GD2-045-1.0-320-H 0.45 0.0177 1.0 3.2 25
3620-000136 GD2-046-1.0-360-H 0.46 0.0181 1.0 3.6 25
3620-000137 GD2-047-1.0-360-H 0.47 0.0185 1.0 3.6 25
3620-000138 GD2-048-1.0-360-H 0.48 0.0189 1.0 3.6 25
3620-000139 GD2-049-1.0-360-H 0.49 0.0193 1.0 3.6 25
3620-000140 GD2-050-1.0-360-H 0.50 0.0197 1.0 3.6 25
3620-000141 GD2-051-1.5-400-H 0.51 0.0201 1.5 4.0 25
3620-000142 GD2-052-1.5-400-H 0.52 0.0205 1.5 4.0 25
3620-000143 GD2-053-1.5-400-H 0.53 0.0209 1.5 4.0 25
3620-000144 GD2-054-1.5-400-H 0.54 0.0213 1.5 4.0 25
3620-000145 GD2-055-1.5-400-H 0.55 0.0217 1.5 4.0 25
3620-000146 GD2-056-1.5-450-H 0.56 0.022 1.5 4.5 25
3620-000147 GD2-057-1.5-450-H 0.57 0.0224 1.5 4.5 25
3620-000148 GD2-058-1.5-450-H 0.58 0.0228 1.5 4.5 25
3620-000149 GD2-059-1.5-450-H 0.59 0.0232 1.5 4.5 25
3620-000150 GD2-060-1.5-450-H 0.60 0.0236 1.5 4.5 25
3620-000151 GD2-061-1.5-470-H 0.61 0.024 1.5 4.7 25
3620-000152 GD2-062-1.5-470-H 0.62 0.0244 1.5 4.7 25
3620-000153 GD2-063-1.5-470-H 0.63 0.0248 1.5 4.7 25
3620-000154 GD2-064-1.5-470-H 0.64 0.0252 1.5 4.7 25
3620-000155 GD2-065-1.5-470-H 0.65 0.0256 1.5 4.7 25
3620-000156 GD2-066-1.5-470-H 0.66 0.026 1.5 4.7 25
3620-000157 GD2-067-1.5-470-H 0.67 0.0264 1.5 4.7 25
3620-000158 GD2-068-1.5-520-H 0.68 0.0268 1.5 5.2 25
3620-000159 GD2-069-1.5-520-H 0.69 0.0272 1.5 5.2 25
3620-000160 GD2-070-1.5-520-H 0.70 0.0276 1.5 5.2 25
3620-000161 GD2-071-1.5-520-H 0.71 0.028 1.5 5.2 25
3620-000162 GD2-072-1.5-520-H 0.72 0.0283 1.5 5.2 25
3620-000163 GD2-073-1.5-520-H 0.73 0.0287 1.5 5.2 25
3620-000164 GD2-074-1.5-520-H 0.74 0.0291 1.5 5.2 25
3620-000165 GD2-075-1.5-520-H 0.75 0.0295 1.5 5.2 25
3620-000166 GD2-076-1.5-550-H 0.76 0.0299 1.5 5.5 25
3620-000167 GD2-077-1.5-550-H 0.77 0.0303 1.5 5.5 25
3620-000168 GD2-078-1.5-550-H 0.78 0.0307 1.5 5.5 25
3620-000169 GD2-079-1.5-550-H 0.79 0.0311 1.5 5.5 25
3620-000170 GD2-080-1.5-550-H 0.80 0.0315 1.5 5.5 25
3620-000171 GD2-081-1.5-550-H 0.81 0.0319 1.5 5.5 25
3620-000172 GD2-082-1.5-550-H 0.82 0.0323 1.5 5.5 25
3620-000173 GD2-083-1.5-550-H 0.83 0.0327 1.5 5.5 25
3620-000174 GD2-084-1.5-550-H 0.84 0.0331 1.5 5.5 25
3620-000175 GD2-085-1.5-550-H 0.85 0.0335 1.5 5.5 25
3620-000176 GD2-086-1.5-600-H 0.86 0.0339 1.5 6.0 25
3620-000177 GD2-087-1.5-600-H 0.87 0.0343 1.5 6.0 25
3620-000178 GD2-088-1.5-600-H 0.88 0.0346 1.5 6.0 25
3620-000179 GD2-089-1.5-600-H 0.89 0.035 1.5 6.0 25
3620-000180 GD2-090-1.5-600-H 0.90 0.0354 1.5 6.0 25
3620-000181 GD2-091-1.5-600-H 0.91 0.0358 1.5 6.0 25
3620-000182 GD2-092-1.5-600-H 0.92 0.0362 1.5 6.0 25
3620-000183 GD2-093-1.5-600-H 0.93 0.0366 1.5 6.0 25
3620-000184 GD2-094-1.5-600-H 0.94 0.037 1.5 6.0 25
3620-000185 GD2-095-1.5-600-H 0.95 0.0374 1.5 6.0 25
3620-000186 GD2-096-1.5-650-H 0.96 0.0378 1.5 6.5 25
3620-000187 GD2-097-1.5-650-H 0.97 0.0382 1.5 6.5 25
3620-000188 GD2-098-1.5-650-H 0.98 0.0386 1.5 6.5 25
3620-000189 GD2-099-1.5-650-H 0.99 0.039 1.5 6.5 25
3620-000190 GD2-100-1.5-650-H 1.00 0.0394 1.5 6.5 25
3620-000191 GD2-101-1.5-650-H 1.01 0.0398 1.5 6.5 25
3620-000192 GD2-102-1.5-650-H 1.02 0.0402 1.5 6.5 25
3620-000193 GD2-103-1.5-650-H 1.03 0.0406 1.5 6.5 25
3620-000194 GD2-104-1.5-650-H 1.04 0.0409 1.5 6.5 25
3620-000195 GD2-105-1.5-650-H 1.05 0.0413 1.5 6.5 25
3620-000196 GD2-106-1.5-700-H 1.06 0.0417 1.5 7.0 25
3620-000197 GD2-107-1.5-700-H 1.07 0.0421 1.5 7.0 25
3620-000198 GD2-108-1.5-700-H 1.08 0.0425 1.5 7.0 25
3620-000199 GD2-109-1.5-700-H 1.09 0.0429 1.5 7.0 25
3620-000200 GD2-110-1.5-700-H 1.10 0.0433 1.5 7.0 25
3620-000201 GD2-111-1.5-700-H 1.11 0.0437 1.5 7.0 25
3620-000202 GD2-112-1.5-700-H 1.12 0.0441 1.5 7.0 25
3620-000203 GD2-113-1.5-700-H 1.13 0.0445 1.5 7.0 25
3620-000204 GD2-114-1.5-700-H 1.14 0.0449 1.5 7.0 25
3620-000205 GD2-115-1.5-700-H 1.15 0.0453 1.5 7.0 25
3620-000206 GD2-116-1.5-750-H 1.16 0.0457 1.5 7.5 25
3620-000207 GD2-117-1.5-750-H 1.17 0.0461 1.5 7.5 25
3620-000208 GD2-118-1.5-750-H 1.18 0.0465 1.5 7.5 25
3620-000209 GD2-119-1.5-750-H 1.19 0.0469 1.5 7.5 25
3620-000210 GD2-120-1.5-750-H 1.20 0.0472 1.5 7.5 25
3620-000211 GD2-121-1.5-750-H 1.21 0.0476 1.5 7.5 25
3620-000212 GD2-122-1.5-750-H 1.22 0.048 1.5 7.5 25
3620-000213 GD2-123-1.5-750-H 1.23 0.0484 1.5 7.5 25
3620-000214 GD2-124-1.5-750-H 1.24 0.0488 1.5 7.5 25
3620-000215 GD2-125-1.5-750-H 1.25 0.0492 1.5 7.5 25
3620-000216 GD2-126-1.5-750-H 1.26 0.0496 1.5 7.5 25
3620-000217 GD2-127-1.5-750-H 1.27 0.0500 1.5 7.5 25
Drill Ø 1.28mm - 2.45mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3620-000218 GD2-128-1.5-750-H 1.28 0.0504 1.5 7.5 25
3620-000219 GD2-129-1.5-750-H 1.29 0.0508 1.5 7.5 25
3620-000220 GD2-130-1.5-750-H 1.3 0.0512 1.5 7.5 25
3620-000221 GD2-131-1.5-850-H 1.31 0.0516 1.5 8.5 25
3620-000222 GD2-132-1.5-850-H 1.32 0.052 1.5 8.5 25
3620-000223 GD2-133-1.5-850-H 1.33 0.0524 1.5 8.5 25
3620-000224 GD2-134-1.5-850-H 1.34 0.0528 1.5 8.5 25
3620-000225 GD2-135-1.5-850-H 1.35 0.0531 1.5 8.5 25
3620-000226 GD2-136-1.5-850-H 1.36 0.0535 1.5 8.5 25
3620-000227 GD2-137-1.5-850-H 1.37 0.0539 1.5 8.5 25
3620-000228 GD2-138-1.5-850-H 1.38 0.0543 1.5 8.5 25
3620-000229 GD2-139-1.5-850-H 1.39 0.0547 1.5 8.5 25
3620-000230 GD2-140-1.5-850-H 1.4 0.0551 1.5 8.5 25
3620-000231 GD2-141-1.5-850-H 1.41 0.0555 1.5 8.5 25
3620-000232 GD2-142-1.5-850-H 1.42 0.0559 1.5 8.5 25
3620-000233 GD2-143-1.5-850-H 1.43 0.0563 1.5 8.5 25
3620-000234 GD2-144-1.5-850-H 1.44 0.0567 1.5 8.5 25
3620-000235 GD2-145-1.5-850-H 1.45 0.0571 1.5 8.5 25
3620-000236 GD2-146-1.5-850-H 1.46 0.0575 1.5 8.5 25
3620-000237 GD2-147-1.5-850-H 1.47 0.0579 1.5 8.5 25
3620-000238 GD2-148-1.5-850-H 1.48 0.0583 1.5 8.5 25
3620-000239 GD2-149-1.5-850-H 1.49 0.0587 1.5 8.5 25
3620-000240 GD2-150-2.0-1000-H 1.5 0.0591 2 10 35
3620-000241 GD2-151-2.0-1000-H 1.51 0.0594 2 10 35
3620-000242 GD2-152-2.0-1000-H 1.52 0.0598 2 10 35
3620-000243 GD2-153-2.0-1000-H 1.53 0.0602 2 10 35
3620-000244 GD2-154-2.0-1000-H 1.54 0.0606 2 10 35
3620-000245 GD2-155-2.0-1000-H 1.55 0.061 2 10 35
3620-000246 GD2-156-2.0-1000-H 1.56 0.0614 2 10 35
3620-000247 GD2-157-2.0-1000-H 1.57 0.0618 2 10 35
3620-000248 GD2-158-2.0-1000-H 1.58 0.0622 2 10 35
3620-000249 GD2-159-2.0-1000-H 1.59 0.0626 2 10 35
3620-000250 GD2-160-2.0-1000-H 1.6 0.063 2 10 35
3620-000251 GD2-161-2.0-1000-H 1.61 0.0634 2 10 35
3620-000252 GD2-162-2.0-1000-H 1.62 0.0638 2 10 35
3620-000253 GD2-163-2.0-1000-H 1.63 0.0642 2 10 35
3620-000254 GD2-164-2.0-1000-H 1.64 0.0646 2 10 35
3620-000255 GD2-165-2.0-1000-H 1.65 0.065 2 10 35
3620-000256 GD2-166-2.0-1000-H 1.66 0.0654 2 10 35
3620-000257 GD2-167-2.0-1000-H 1.67 0.0657 2 10 35
3620-000258 GD2-168-2.0-1000-H 1.68 0.0661 2 10 35
3620-000259 GD2-169-2.0-1000-H 1.69 0.0665 2 10 35
3620-000260 GD2-170-2.0-1000-H 1.7 0.0669 2 10 35
3620-000261 GD2-171-2.0-1000-H 1.71 0.0673 2 10 35
3620-000262 GD2-172-2.0-1000-H 1.72 0.0677 2 10 35
3620-000263 GD2-173-2.0-1000-H 1.73 0.0681 2 10 35
3620-000264 GD2-174-2.0-1000-H 1.74 0.0685 2 10 35
3620-000265 GD2-175-2.0-1000-H 1.75 0.0689 2 10 35
3620-000266 GD2-176-2.0-1000-H 1.76 0.0693 2 10 35
3620-000267 GD2-177-2.0-1100-H 1.77 0.0697 2 11 35
3620-000268 GD2-178-2.0-1100-H 1.78 0.0701 2 11 35
3620-000269 GD2-179-2.0-1100-H 1.79 0.0705 2 11 35
3620-000270 GD2-180-2.0-1100-H 1.8 0.0709 2 11 35
3620-000271 GD2-181-2.0-1100-H 1.81 0.0713 2 11 35
3620-000272 GD2-182-2.0-1100-H 1.82 0.0717 2 11 35
3620-000273 GD2-183-2.0-1100-H 1.83 0.072 2 11 35
3620-000274 GD2-184-2.0-1100-H 1.84 0.0724 2 11 35
3620-000275 GD2-185-2.0-1100-H 1.85 0.0728 2 11 35
3620-000276 GD2-186-2.0-1100-H 1.86 0.0732 2 11 35
3620-000277 GD2-187-2.0-1100-H 1.87 0.0736 2 11 35
3620-000278 GD2-188-2.0-1100-H 1.88 0.074 2 11 35
3620-000279 GD2-189-2.0-1100-H 1.89 0.0744 2 11 35
3620-000280 GD2-190-2.0-1100-H 1.9 0.0748 2 11 35
3620-000281 GD2-191-2.0-1100-H 1.91 0.0752 2 11 35
3620-000282 GD2-192-2.0-1100-H 1.92 0.0756 2 11 35
3620-000283 GD2-193-2.0-1100-H 1.93 0.076 2 11 35
3620-000284 GD2-194-2.0-1100-H 1.94 0.0764 2 11 35
3620-000285 GD2-195-2.0-1100-H 1.95 0.0768 2 11 35
3620-000286 GD2-196-2.0-1100-H 1.96 0.0772 2 11 35
3620-000287 GD2-197-2.0-1100-H 1.97 0.0776 2 11 35
3620-000288 GD2-198-2.0-1100-H 1.98 0.078 2 11 35
3620-000289 GD2-199-2.0-1100-H 1.99 0.0783 2 11 35
3620-000290 GD2-200-2.0-1100-H 2 0.0787 2 11 35
3620-000291 GD2-201-2.5-1200-H 2.01 0.0791 2.5 12 35
3620-000292 GD2-202-2.5-1200-H 2.02 0.0795 2.5 12 35
3620-000293 GD2-203-2.5-1200-H 2.03 0.0799 2.5 12 35
3620-000294 GD2-204-2.5-1200-H 2.04 0.0803 2.5 12 35
3620-000295 GD2-205-2.5-1200-H 2.05 0.0807 2.5 12 35
3620-000296 GD2-206-2.5-1200-H 2.06 0.0811 2.5 12 35
3620-000297 GD2-207-2.5-1200-H 2.07 0.0815 2.5 12 35
3620-000298 GD2-208-2.5-1200-H 2.08 0.0819 2.5 12 35
3620-000299 GD2-209-2.5-1200-H 2.09 0.0823 2.5 12 35
3620-000300 GD2-210-2.5-1200-H 2.1 0.0827 2.5 12 35
3620-000301 GD2-211-2.5-1200-H 2.11 0.0831 2.5 12 35
3620-000302 GD2-212-2.5-1200-H 2.12 0.0835 2.5 12 35
3620-000303 GD2-213-2.5-1200-H 2.13 0.0839 2.5 12 35
3620-000304 GD2-214-2.5-1200-H 2.14 0.0843 2.5 12 35
3620-000305 GD2-215-2.5-1200-H 2.15 0.0846 2.5 12 35
3620-000306 GD2-216-2.5-1200-H 2.16 0.085 2.5 12 35
3620-000307 GD2-217-2.5-1200-H 2.17 0.0854 2.5 12 35
3620-000308 GD2-218-2.5-1200-H 2.18 0.0858 2.5 12 35
3620-000309 GD2-219-2.5-1200-H 2.19 0.0862 2.5 12 35
3620-000310 GD2-220-2.5-1200-H 2.2 0.0866 2.5 12 35
3620-000311 GD2-221-2.5-1400-H 2.21 0.087 2.5 14 35
3620-000312 GD2-222-2.5-1400-H 2.22 0.0874 2.5 14 35
3620-000313 GD2-223-2.5-1400-H 2.23 0.0878 2.5 14 35
3620-000314 GD2-224-2.5-1400-H 2.24 0.0882 2.5 14 35
3620-000315 GD2-225-2.5-1400-H 2.25 0.0886 2.5 14 35
3620-000316 GD2-226-2.5-1400-H 2.26 0.089 2.5 14 35
3620-000317 GD2-227-2.5-1400-H 2.27 0.0894 2.5 14 35
3620-000318 GD2-228-2.5-1400-H 2.28 0.0898 2.5 14 35
3620-000319 GD2-229-2.5-1400-H 2.29 0.0902 2.5 14 35
3620-000320 GD2-230-2.5-1400-H 2.3 0.0906 2.5 14 35
3620-000321 GD2-231-2.5-1400-H 2.31 0.0909 2.5 14 35
3620-000322 GD2-232-2.5-1400-H 2.32 0.0913 2.5 14 35
3620-000323 GD2-233-2.5-1400-H 2.33 0.0917 2.5 14 35
3620-000324 GD2-234-2.5-1400-H 2.34 0.0921 2.5 14 35
3620-000325 GD2-235-2.5-1400-H 2.35 0.0925 2.5 14 35
3620-000326 GD2-236-2.5-1400-H 2.36 0.0929 2.5 14 35
3620-000327 GD2-237-2.5-1400-H 2.37 0.0933 2.5 14 35
3620-000328 GD2-238-2.5-1400-H 2.38 0.0937 2.5 14 35
3620-000329 GD2-239-2.5-1400-H 2.39 0.0941 2.5 14 35
3620-000330 GD2-240-2.5-1400-H 2.4 0.0945 2.5 14 35
3620-000331 GD2-241-2.5-1400-H 2.41 0.0949 2.5 14 35
3620-000332 GD2-242-2.5-1400-H 2.42 0.0953 2.5 14 35
3620-000333 GD2-243-2.5-1400-H 2.43 0.0957 2.5 14 35
3620-000334 GD2-244-2.5-1400-H 2.44 0.0961 2.5 14 35
3620-000335 GD2-245-2.5-1400-H 2.45 0.0965 2.5 14 35
Drill Ø 2.46mm - 3.00mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3620-000336 GD2-246-2.5-1400-H 2.46 0.0969 2.5 14 35
3620-000337 GD2-247-2.5-1400-H 2.47 0.0972 2.5 14 35
3620-000338 GD2-248-2.5-1400-H 2.48 0.0976 2.5 14 35
3620-000339 GD2-249-2.5-1400-H 2.49 0.098 2.5 14 35
3620-000340 GD2-250-2.5-1400-H 2.5 0.0984 2.5 14 35
3620-000341 GD2-251-300-1600-H 2.51 0.0988 3 16 40
3620-000342 GD2-252-300-1600-H 2.52 0.0992 3 16 40
3620-000343 GD2-253-300-1600-H 2.53 0.0996 3 16 40
3620-000344 GD2-254-300-1600-H 2.54 0.1 3 16 40
3620-000345 GD2-255-300-1600-H 2.55 0.1004 3 16 40
3620-000346 GD2-256-300-1600-H 2.56 0.1008 3 16 40
3620-000347 GD2-257-300-1600-H 2.57 0.1012 3 16 40
3620-000348 GD2-258-300-1600-H 2.58 0.1016 3 16 40
3620-000349 GD2-259-300-1600-H 2.59 0.102 3 16 40
3620-000350 GD2-260-300-1600-H 2.6 0.1024 3 16 40
3620-000351 GD2-261-300-1600-H 2.61 0.1028 3 16 40
3620-000352 GD2-262-300-1600-H 2.62 0.1031 3 16 40
3620-000353 GD2-263-300-1600-H 2.63 0.1035 3 16 40
3620-000354 GD2-264-300-1600-H 2.64 0.1039 3 16 40
3620-000355 GD2-265-300-1600-H 2.65 0.1043 3 16 40
3620-000356 GD2-266-300-1600-H 2.66 0.1047 3 16 40
3620-000357 GD2-267-300-1600-H 2.67 0.1051 3 16 40
3620-000358 GD2-268-300-1600-H 2.68 0.1055 3 16 40
3620-000359 GD2-269-300-1600-H 2.69 0.1059 3 16 40
3620-000360 GD2-270-300-1600-H 2.7 0.1063 3 16 40
3620-000361 GD2-271-300-1600-H 2.71 0.1067 3 16 40
3620-000362 GD2-272-300-1600-H 2.72 0.1071 3 16 40
3620-000363 GD2-273-300-1600-H 2.73 0.1075 3 16 40
3620-000364 GD2-274-300-1600-H 2.74 0.1079 3 16 40
3620-000365 GD2-275-300-1600-H 2.75 0.1083 3 16 40
3620-000366 GD2-276-300-1800-H 2.76 0.1087 3 18 40
3620-000367 GD2-277-300-1800-H 2.77 0.1091 3 18 40
3620-000368 GD2-278-300-1800-H 2.78 0.1094 3 18 40
3620-000369 GD2-279-300-1800-H 2.79 0.1098 3 18 40
3620-000370 GD2-280-300-1800-H 2.8 0.1102 3 18 40
3620-000371 GD2-281-300-1800-H 2.81 0.1106 3 18 40
3620-000372 GD2-282-300-1800-H 2.82 0.111 3 18 40
3620-000373 GD2-283-300-1800-H 2.83 0.1114 3 18 40
3620-000374 GD2-284-300-1800-H 2.84 0.1118 3 18 40
3620-000375 GD2-285-300-1800-H 2.85 0.1122 3 18 40
3620-000376 GD2-286-300-1800-H 2.86 0.1126 3 18 40
3620-000377 GD2-287-300-1800-H 2.87 0.113 3 18 40
3620-000378 GD2-288-300-1800-H 2.88 0.1134 3 18 40
3620-000379 GD2-289-300-1800-H 2.89 0.1138 3 18 40
3620-000380 GD2-290-300-1800-H 2.9 0.1142 3 18 40
3620-000381 GD2-291-300-1800-H 2.91 0.1146 3 18 40
3620-000382 GD2-292-300-1800-H 2.92 0.115 3 18 40
3620-000383 GD2-293-300-1800-H 2.93 0.1154 3 18 40
3620-000384 GD2-294-300-1800-H 2.94 0.1157 3 18 40
3620-000385 GD2-295-300-1800-H 2.95 0.1161 3 18 40
3620-000386 GD2-296-300-1800-H 2.96 0.1165 3 18 40
3620-000387 GD2-297-300-1800-H 2.97 0.1169 3 18 40
3620-000388 GD2-298-300-1800-H 2.98 0.1173 3 18 40
3620-000389 GD2-299-300-1800-H 2.99 0.1177 3 18 40
3620-000390 GD2-300-300-1800-H 3 0.1181 3 18 40

3630

3630 Series

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3630 Solid Carbide 2-3 X Dia 120° 24° 2 h6 (+0.000 -0.006mm) No

Click Below To Expand

Drill Ø 0.2mm - 3.00mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3630-000100 GD3-020-1.5-090-C 0.2 0.0079 1.5 0.9 30
3630-000101 GD3-025-1.5-090-C 0.25 0.0098 1.5 0.9 30
3630-000102 GD3-030-1.5-090-C 0.3 0.0118 1.5 0.9 30
3630-000103 GD3-035-1.5-012-C 0.35 0.0138 1.5 1.2 30
3630-000104 GD3-040-1.5-150-C 0.4 0.0157 1.5 1.5 30
3630-000105 GD3-045-1.5-150-C 0.45 0.0177 1.5 1.5 30
3630-000106 GD3-050-1.5-190-C 0.5 0.0197 1.5 1.9 30
3630-000107 GD3-055-1.5-190-C 0.55 0.0217 1.5 1.9 30
3630-000108 GD3-060-1.5-190-C 0.6 0.0236 1.5 1.9 30
3630-000109 GD3-065-1.5-210-C 0.65 0.0256 1.5 2.1 30
3630-000110 GD3-070-1.5-240-C 0.7 0.0276 1.5 2.4 30
3630-000111 GD3-075-1.5-240-C 0.75 0.0295 1.5 2.4 30
3630-000112 GD3-080-1.5-260-C 0.8 0.0315 1.5 2.6 30
3630-000113 GD3-085-1.5-260-C 0.85 0.0335 1.5 2.6 30
3630-000114 GD3-090-1.5-300-C 0.9 0.0354 1.5 3 30
3630-000115 GD3-095-1.5-300-C 0.95 0.0374 1.5 3 30
3630-000116 GD3-100-1.5-340-C 1 0.0394 1.5 3.4 30
3630-000117 GD3-105-1.5-340-C 1.05 0.0413 1.5 3.4 30
3630-000118 GD3-110-1.5-380-C 1.1 0.0433 1.5 3.8 30
3630-000119 GD3-115-1.5-380-C 1.15 0.0453 1.5 3.8 30
3630-000120 GD3-120-1.5-420-C 1.2 0.0472 1.5 4.2 30
3630-000121 GD3-125-1.5-420-C 1.25 0.0492 1.5 4.2 30
3630-000122 GD3-130-1.5-420-C 1.3 0.0512 1.5 4.2 30
3630-000123 GD3-135-1.5-470-C 1.35 0.0531 1.5 4.7 30
3630-000124 GD3-140-1.5-470-C 1.4 0.0551 1.5 4.7 30
3630-000125 GD3-145-1.5-470-C 1.45 0.0571 1.5 4.7 30
3630-000126 GD3-150-2.0-470-C 1.5 0.0591 2 4.7 38
3630-000127 GD3-160-2.0-540-C 1.6 0.063 2 5.4 38
3630-000128 GD3-170-2.0-540-C 1.7 0.0669 2 5.4 38
3630-000129 GD3-180-2.0-650-C 1.8 0.0709 2 6.5 38
3630-000130 GD3-190-2.0-650-C 1.9 0.0748 2 6.5 38
3630-000131 GD3-200-3.0-650-C 2 0.0787 3 6.5 38
3630-000132 GD3-210-3.0-650-C 2.1 0.0827 3 6.5 38
3630-000133 GD3-220-3.0-650-C 2.2 0.0866 3 6.5 38
3630-000134 GD3-230-3.0-650-C 2.3 0.0906 3 6.5 38
3630-000135 GD3-240-3.0-650-C 2.4 0.0945 3 6.5 38
3630-000136 GD3-250-3.0-750-C 2.5 0.0984 3 7.5 38
3630-000137 GD3-260-3.0-750-C 2.6 0.1024 3 7.5 38
3630-000138 GD3-270-3.0-750-C 2.7 0.1063 3 7.5 38
3630-000139 GD3-280-3.0-750-C 2.8 0.1102 3 7.5 38
3630-000140 GD3-290-3.0-750-C 2.9 0.1142 3 7.5 38
3630-000141 GD3-300-3.0-750-C 3 0.1181 3 7.5 38

3640

3640 Series

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3640 Solid Carbide 4-5 X Dia 120° 35° 2 h6 (+0.000 -0.006mm) No

Click Below To Expand

Drill Ø .2mm - 1.37mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3640-000100 GD4-020-1.0-110-C 0.20 0.0079 1.0 1.1 25
3640-000101 GD4-021-1.0-110-C 0.21 0.0083 1.0 1.1 25
3640-000102 GD4-022-1.0-110-C 0.22 0.0087 1.0 1.1 25
3640-000103 GD4-023-1.0-110-C 0.23 0.0091 1.0 1.1 25
3640-000104 GD4-024-1.0-110-C 0.24 0.0094 1.0 1.1 25
3640-000105 GD4-025-1.0-130-C 0.25 0.0098 1.0 1.3 25
3640-000106 GD4-026-1.0-130-C 0.26 0.0102 1.0 1.3 25
3640-000107 GD4-027-1.0-130-C 0.27 0.0106 1.0 1.3 25
3640-000108 GD4-028-1.0-130-C 0.28 0.011 1.0 1.3 25
3640-000109 GD4-029-1.0-130-C 0.29 0.0114 1.0 1.3 25
3640-000110 GD4-030-1.0-160-C 0.30 0.0118 1.0 1.6 25
3640-000111 GD4-031-1.0-160-C 0.31 0.0122 1.0 1.6 25
3640-000112 GD4-032-1.0-160-C 0.32 0.0126 1.0 1.6 25
3640-000113 GD4-033-1.0-160-C 0.33 0.013 1.0 1.6 25
3640-000114 GD4-034-1.0-160-C 0.34 0.0134 1.0 1.6 25
3640-000115 GD4-035-1.0-160-C 0.35 0.0138 1.0 1.6 25
3640-000116 GD4-036-1.0-160-C 0.36 0.0142 1.0 1.6 25
3640-000117 GD4-037-1.0-160-C 0.37 0.0146 1.0 1.6 25
3640-000118 GD4-038-1.0-160-C 0.38 0.015 1.0 1.6 25
3640-000119 GD4-039-1.0-200-C 0.39 0.0154 1.0 2.0 25
3640-000120 GD4-040-1.0-200-C 0.40 0.0157 1.0 2.0 25
3640-000121 GD4-041-1.0-200-C 0.41 0.0161 1.0 2.0 25
3640-000122 GD4-042-1.0-200-C 0.42 0.0165 1.0 2.0 25
3640-000123 GD4-043-1.0-200-C 0.43 0.0169 1.0 2.0 25
3640-000124 GD4-044-1.0-200-C 0.44 0.0173 1.0 2.0 25
3640-000125 GD4-045-1.0-200-C 0.45 0.0177 1.0 2.0 25
3640-000126 GD4-046-1.0-200-C 0.46 0.0181 1.0 2.0 25
3640-000127 GD4-047-1.0-200-C 0.47 0.0185 1.0 2.0 25
3640-000128 GD4-048-1.0-200-C 0.48 0.0189 1.0 2.0 25
3640-000129 GD4-049-1.0-200-C 0.49 0.0193 1.0 2.0 25
3640-000130 GD4-050-1.0-240-C 0.50 0.0197 1.0 2.4 25
3640-000131 GD4-051-1.0-240-C 0.51 0.0201 1.0 2.4 25
3640-000132 GD4-052-1.0-240-C 0.52 0.0205 1.0 2.4 25
3640-000133 GD4-053-1.0-240-C 0.53 0.0209 1.0 2.4 25
3640-000134 GD4-054-1.0-280-C 0.54 0.0213 1.0 2.8 25
3640-000135 GD4-055-1.0-280-C 0.55 0.0217 1.0 2.8 25
3640-000136 GD4-056-1.0-280-C 0.56 0.022 1.0 2.8 25
3640-000137 GD4-057-1.0-280-C 0.57 0.0224 1.0 2.8 25
3640-000138 GD4-058-1.0-280-C 0.58 0.0228 1.0 2.8 25
3640-000139 GD4-059-1.0-280-C 0.59 0.0232 1.0 2.8 25
3640-000140 GD4-060-1.5-280-C 0.60 0.0236 1.5 2.8 30
3640-000141 GD4-061-1.5-330-C 0.61 0.024 1.5 3.3 30
3640-000142 GD4-062-1.5-330-C 0.62 0.0244 1.5 3.3 30
3640-000143 GD4-063-1.5-330-C 0.63 0.0248 1.5 3.3 30
3640-000144 GD4-064-1.5-330-C 0.64 0.0252 1.5 3.3 30
3640-000145 GD4-065-1.5-330-C 0.65 0.0256 1.5 3.3 30
3640-000146 GD4-066-1.5-330-C 0.66 0.026 1.5 3.3 30
3640-000147 GD4-067-1.5-330-C 0.67 0.0264 1.5 3.3 30
3640-000148 GD4-068-1.5-380-C 0.68 0.0268 1.5 3.8 30
3640-000149 GD4-069-1.5-380-C 0.69 0.0272 1.5 3.8 30
3640-000150 GD4-070-1.5-380-C 0.70 0.0276 1.5 3.8 30
3640-000151 GD4-071-1.5-380-C 0.71 0.028 1.5 3.8 30
3640-000152 GD4-072-1.5-380-C 0.72 0.0283 1.5 3.8 30
3640-000153 GD4-073-1.5-380-C 0.73 0.0287 1.5 3.8 30
3640-000154 GD4-074-1.5-380-C 0.74 0.0291 1.5 3.8 30
3640-000155 GD4-075-1.5-380-C 0.75 0.0295 1.5 3.8 30
3640-000156 GD4-076-1.5-420-C 0.76 0.0299 1.5 4.2 30
3640-000157 GD4-077-1.5-420-C 0.77 0.0303 1.5 4.2 30
3640-000158 GD4-078-1.5-420-C 0.78 0.0307 1.5 4.2 30
3640-000159 GD4-079-1.5-420-C 0.79 0.0311 1.5 4.2 30
3640-000160 GD4-080-1.5-440-C 0.80 0.0315 1.5 4.4 30
3640-000161 GD4-081-1.5-440-C 0.81 0.0319 1.5 4.4 30
3640-000162 GD4-082-1.5-440-C 0.82 0.0323 1.5 4.4 30
3640-000163 GD4-083-1.5-440-C 0.83 0.0327 1.5 4.4 30
3640-000164 GD4-084-1.5-440-C 0.84 0.0331 1.5 4.4 30
3640-000165 GD4-085-1.5-440-C 0.85 0.0335 1.5 4.4 30
3640-000166 GD4-086-1.5-480-C 0.86 0.0339 1.5 4.8 30
3640-000167 GD4-087-1.5-480-C 0.87 0.0343 1.5 4.8 30
3640-000168 GD4-088-1.5-480-C 0.88 0.0346 1.5 4.8 30
3640-000169 GD4-089-1.5-480-C 0.89 0.035 1.5 4.8 30
3640-000170 GD4-090-1.5-480-C 0.90 0.0354 1.5 4.8 30
3640-000171 GD4-091-1.5-480-C 0.91 0.0358 1.5 4.8 30
3640-000172 GD4-092-1.5-480-C 0.92 0.0362 1.5 4.8 30
3640-000173 GD4-093-1.5-480-C 0.93 0.0366 1.5 4.8 30
3640-000174 GD4-094-1.5-480-C 0.94 0.037 1.5 4.8 30
3640-000175 GD4-095-1.5-480-C 0.95 0.0374 1.5 4.8 30
3640-000176 GD4-096-1.5-480-C 0.96 0.0378 1.5 4.8 30
3640-000177 GD4-097-1.5-480-C 0.97 0.0382 1.5 4.8 30
3640-000178 GD4-098-1.5-480-C 0.98 0.0386 1.5 4.8 30
3640-000179 GD4-099-1.5-480-C 0.99 0.039 1.5 4.8 30
3640-000180 GD4-100-1.5-480-C 1.00 0.0394 1.5 4.8 30
3640-000181 GD4-101-1.5-480-C 1.01 0.0398 1.5 4.8 30
3640-000182 GD4-102-1.5-480-C 1.02 0.0402 1.5 4.8 30
3640-000183 GD4-103-1.5-480-C 1.03 0.0406 1.5 4.8 30
3640-000184 GD4-104-1.5-480-C 1.04 0.0409 1.5 4.8 30
3640-000185 GD4-105-1.5-480-C 1.05 0.0413 1.5 4.8 30
3640-000186 GD4-106-1.5-480-C 1.06 0.0417 1.5 4.8 30
3640-000187 GD4-107-1.5-480-C 1.07 0.0421 1.5 4.8 30
3640-000188 GD4-108-1.5-480-C 1.08 0.0425 1.5 4.8 30
3640-000189 GD4-109-1.5-480-C 1.09 0.0429 1.5 4.8 30
3640-000190 GD4-110-1.5-540-C 1.10 0.0433 1.5 5.4 30
3640-000191 GD4-111-1.5-540-C 1.11 0.0437 1.5 5.4 30
3640-000192 GD4-112-1.5-540-C 1.12 0.0441 1.5 5.4 30
3640-000193 GD4-113-1.5-540-C 1.13 0.0445 1.5 5.4 30
3640-000194 GD4-114-1.5-540-C 1.14 0.0449 1.5 5.4 30
3640-000195 GD4-115-1.5-540-C 1.15 0.0453 1.5 5.4 30
3640-000196 GD4-116-1.5-540-C 1.16 0.0457 1.5 5.4 30
3640-000197 GD4-117-1.5-540-C 1.17 0.0461 1.5 5.4 30
3640-000198 GD4-118-1.5-540-C 1.18 0.0465 1.5 5.4 30
3640-000199 GD4-119-1.5-540-C 1.19 0.0469 1.5 5.4 30
3640-000200 GD4-120-1.5-600-C 1.20 0.0472 1.5 6.0 30
3640-000201 GD4-121-1.5-600-C 1.21 0.0476 1.5 6.0 30
3640-000202 GD4-122-1.5-600-C 1.22 0.048 1.5 6.0 30
3640-000203 GD4-123-1.5-600-C 1.23 0.0484 1.5 6.0 30
3640-000204 GD4-124-1.5-600-C 1.24 0.0488 1.5 6.0 30
3640-000205 GD4-125-1.5-600-C 1.25 0.0492 1.5 6.0 30
3640-000206 GD4-126-1.5-600-C 1.26 0.0496 1.5 6.0 30
3640-000207 GD4-127-1.5-600-C 1.27 0.05 1.5 6.0 30
3640-000208 GD4-128-1.5-600-C 1.28 0.0504 1.5 6.0 30
3640-000209 GD4-129-1.5-600-C 1.29 0.0508 1.5 6.0 30
3640-000210 GD4-130-1.5-670-C 1.30 0.0512 1.5 6.7 30
3640-000211 GD4-131-1.5-670-C 1.31 0.0516 1.5 6.7 30
3640-000212 GD4-132-1.5-670-C 1.32 0.052 1.5 6.7 30
3640-000213 GD4-133-1.5-670-C 1.33 0.0524 1.5 6.7 30
3640-000214 GD4-134-1.5-670-C 1.34 0.0528 1.5 6.7 30
3640-000215 GD4-135-1.5-670-C 1.35 0.0531 1.5 6.7 30
3640-000216 GD4-136-1.5-670-C 1.36 0.0535 1.5 6.7 30
3640-000217 GD4-137-1.5-670-C 1.37 0.0539 1.5 6.7 30
Drill Ø 1.38mm - 2.55mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3640-000218 GD4-138-1.5-670-C 1.38 0.0543 1.5 6.7 30
3640-000219 GD4-139-1.5-670-C 1.39 0.0547 1.5 6.7 30
3640-000220 GD4-140-1.5-670-C 1.4 0.0551 1.5 6.7 30
3640-000221 GD4-141-1.5-670-C 1.41 0.0555 1.5 6.7 30
3640-000222 GD4-142-1.5-670-C 1.42 0.0559 1.5 6.7 30
3640-000223 GD4-143-1.5-670-C 1.43 0.0563 1.5 6.7 30
3640-000224 GD4-144-1.5-670-C 1.44 0.0567 1.5 6.7 30
3640-000225 GD4-145-1.5-670-C 1.45 0.0571 1.5 6.7 30
3640-000226 GD4-146-1.5-670-C 1.46 0.0575 1.5 6.7 30
3640-000227 GD4-147-1.5-670-C 1.47 0.0579 1.5 6.7 30
3640-000228 GD4-148-1.5-670-C 1.48 0.0583 1.5 6.7 30
3640-000229 GD4-149-1.5-670-C 1.49 0.0587 1.5 6.7 30
3640-000230 GD4-150-2.0-720-C 1.5 0.0591 2 7.2 38
3640-000231 GD4-151-2.0-720-C 1.51 0.0594 2 7.2 38
3640-000232 GD4-152-2.0-720-C 1.52 0.0598 2 7.2 38
3640-000233 GD4-153-2.0-720-C 1.53 0.0602 2 7.2 38
3640-000234 GD4-154-2.0-720-C 1.54 0.0606 2 7.2 38
3640-000235 GD4-155-2.0-720-C 1.55 0.061 2 7.2 38
3640-000236 GD4-156-2.0-720-C 1.56 0.0614 2 7.2 38
3640-000237 GD4-157-2.0-720-C 1.57 0.0618 2 7.2 38
3640-000238 GD4-158-2.0-720-C 1.58 0.0622 2 7.2 38
3640-000239 GD4-159-2.0-720-C 1.59 0.0626 2 7.2 38
3640-000240 GD4-156-2.0-720-C 1.6 0.063 2 7.2 38
3640-000241 GD4-161-2.0-720-C 1.61 0.0634 2 7.2 38
3640-000242 GD4-162-2.0-720-C 1.62 0.0638 2 7.2 38
3640-000243 GD4-163-2.0-720-C 1.63 0.0642 2 7.2 38
3640-000244 GD4-164-2.0-720-C 1.64 0.0646 2 7.2 38
3640-000245 GD4-165-2.0-720-C 1.65 0.065 2 7.2 38
3640-000246 GD4-166-2.0-720-C 1.66 0.0654 2 7.2 38
3640-000247 GD4-167-2.0-720-C 1.67 0.0657 2 7.2 38
3640-000248 GD4-168-2.0-720-C 1.68 0.0661 2 7.2 38
3640-000249 GD4-169-2.0-720-C 1.69 0.0665 2 7.2 38
3640-000250 GD4-170-2.0-720-C 1.7 0.0669 2 7.2 38
3640-000251 GD4-171-2.0-720-C 1.71 0.0673 2 7.2 38
3640-000252 GD4-172-2.0-720-C 1.72 0.0677 2 7.2 38
3640-000253 GD4-173-2.0-720-C 1.73 0.0681 2 7.2 38
3640-000254 GD4-174-2.0-720-C 1.74 0.0685 2 7.2 38
3640-000255 GD4-175-2.0-720-C 1.75 0.0689 2 7.2 38
3640-000256 GD4-176-2.0-720-C 1.76 0.0693 2 7.2 38
3640-000257 GD4-177-2.0-720-C 1.77 0.0697 2 7.2 38
3640-000258 GD4-178-2.0-720-C 1.78 0.0701 2 7.2 38
3640-000259 GD4-179-2.0-720-C 1.79 0.0705 2 7.2 38
3640-000260 GD4-180-2.0-840-C 1.8 0.0709 2 8.4 38
3640-000261 GD4-181-2.0-840-C 1.81 0.0713 2 8.4 38
3640-000262 GD4-182-2.0-840-C 1.82 0.0717 2 8.4 38
3640-000263 GD4-183-2.0-840-C 1.83 0.072 2 8.4 38
3640-000264 GD4-184-2.0-840-C 1.84 0.0724 2 8.4 38
3640-000265 GD4-185-2.0-840-C 1.85 0.0728 2 8.4 38
3640-000266 GD4-186-2.0-840-C 1.86 0.0732 2 8.4 38
3640-000267 GD4-187-2.0-840-C 1.87 0.0736 2 8.4 38
3640-000268 GD4-188-2.0-840-C 1.88 0.074 2 8.4 38
3640-000269 GD4-189-2.0-840-C 1.89 0.0744 2 8.4 38
3640-000270 GD4-190-2.0-840-C 1.9 0.0748 2 8.4 38
3640-000271 GD4-191-2.0-840-C 1.91 0.0752 2 8.4 38
3640-000272 GD4-192-2.0-840-C 1.92 0.0756 2 8.4 38
3640-000273 GD4-193-2.0-840-C 1.93 0.076 2 8.4 38
3640-000274 GD4-194-2.0-840-C 1.94 0.0764 2 8.4 38
3640-000275 GD4-195-2.0-840-C 1.95 0.0768 2 8.4 38
3640-000276 GD4-196-2.0-840-C 1.96 0.0772 2 8.4 38
3640-000277 GD4-197-2.0-840-C 1.97 0.0776 2 8.4 38
3640-000278 GD4-198-2.0-840-C 1.98 0.078 2 8.4 38
3640-000279 GD4-199-2.0-840-C 1.99 0.0783 2 8.4 38
3640-000280 GD4-200-3.0-1200-C 2 0.0787 3 12 38
3640-000281 GD4-201-3.0-1200-C 2.01 0.0791 3 12 38
3640-000282 GD4-202-3.0-1200-C 2.02 0.0795 3 12 38
3640-000283 GD4-203-3.0-1200-C 2.03 0.0799 3 12 38
3640-000284 GD4-204-3.0-1200-C 2.04 0.0803 3 12 38
3640-000285 GD4-205-3.0-1200-C 2.05 0.0807 3 12 38
3640-000286 GD4-206-3.0-1200-C 2.06 0.0811 3 12 38
3640-000287 GD4-207-3.0-1200-C 2.07 0.0815 3 12 38
3640-000288 GD4-208-3.0-1200-C 2.08 0.0819 3 12 38
3640-000289 GD4-209-3.0-1200-C 2.09 0.0823 3 12 38
3640-000290 GD4-210-3.0-1200-C 2.1 0.0827 3 12 38
3640-000291 GD4-211-3.0-1200-C 2.11 0.0831 3 12 38
3640-000292 GD4-212-3.0-1200-C 2.12 0.0835 3 12 38
3640-000293 GD4-213-3.0-1200-C 2.13 0.0839 3 12 38
3640-000294 GD4-214-3.0-1200-C 2.14 0.0843 3 12 38
3640-000295 GD4-215-3.0-1200-C 2.15 0.0846 3 12 38
3640-000296 GD4-216-3.0-1200-C 2.16 0.085 3 12 38
3640-000297 GD4-217-3.0-1200-C 2.17 0.0854 3 12 38
3640-000298 GD4-218-3.0-1200-C 2.18 0.0858 3 12 38
3640-000299 GD4-219-3.0-1200-C 2.19 0.0862 3 12 38
3640-000300 GD4-220-3.0-1200-C 2.2 0.0866 3 12 38
3640-000301 GD4-221-3.0-1200-C 2.21 0.087 3 12 38
3640-000302 GD4-222-3.0-1200-C 2.22 0.0874 3 12 38
3640-000303 GD4-223-3.0-1200-C 2.23 0.0878 3 12 38
3640-000304 GD4-224-3.0-1200-C 2.24 0.0882 3 12 38
3640-000305 GD4-225-3.0-1200-C 2.25 0.0886 3 12 38
3640-000306 GD4-226-3.0-1200-C 2.26 0.089 3 12 38
3640-000307 GD4-227-3.0-1200-C 2.27 0.0894 3 12 38
3640-000308 GD4-228-3.0-1200-C 2.28 0.0898 3 12 38
3640-000309 GD4-229-3.0-1200-C 2.29 0.0902 3 12 38
3640-000310 GD4-230-3.0-1200-C 2.3 0.0906 3 12 38
3640-000311 GD4-231-3.0-1200-C 2.31 0.0909 3 12 38
3640-000312 GD4-232-3.0-1200-C 2.32 0.0913 3 12 38
3640-000313 GD4-233-3.0-1200-C 2.33 0.0917 3 12 38
3640-000314 GD4-234-3.0-1200-C 2.34 0.0921 3 12 38
3640-000315 GD4-235-3.0-1200-C 2.35 0.0925 3 12 38
3640-000316 GD4-236-3.0-1200-C 2.36 0.0929 3 12 38
3640-000317 GD4-237-3.0-1200-C 2.37 0.0933 3 12 38
3640-000318 GD4-238-3.0-1200-C 2.38 0.0937 3 12 38
3640-000319 GD4-239-3.0-1200-C 2.39 0.0941 3 12 38
3640-000320 GD4-240-3.0-1200-C 2.4 0.0945 3 12 38
3640-000321 GD4-241-3.0-1200-C 2.41 0.0949 3 12 38
3640-000322 GD4-242-3.0-1200-C 2.42 0.0953 3 12 38
3640-000323 GD4-243-3.0-1200-C 2.43 0.0957 3 12 38
3640-000324 GD4-244-3.0-1200-C 2.44 0.0961 3 12 38
3640-000325 GD4-245-3.0-1200-C 2.45 0.0965 3 12 38
3640-000326 GD4-246-3.0-1200-C 2.46 0.0969 3 12 38
3640-000327 GD4-247-3.0-1200-C 2.47 0.0972 3 12 38
3640-000328 GD4-248-3.0-1200-C 2.48 0.0976 3 12 38
3640-000329 GD4-249-3.0-1200-C 2.49 0.098 3 12 38
3640-000330 GD4-250-3.0-1400-C 2.5 0.0984 3 14 38
3640-000331 GD4-251-3.0-1400-C 2.51 0.0988 3 14 38
3640-000332 GD4-252-3.0-1400-C 2.52 0.0992 3 14 38
3640-000333 GD4-253-3.0-1400-C 2.53 0.0996 3 14 38
3640-000334 GD4-254-3.0-1400-C 2.54 0.1 3 14 38
3640-000335 GD4-255-3.0-1400-C 2.55 0.1004 3 14 38
Drill Ø 2.56mm - 3.00mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3640-000336 GD4-256-3.0-1400-C 2.56 0.1008 3.0 14 38
3640-000337 GD4-257-3.0-1400-C 2.57 0.1012 3.0 14 38
3640-000338 GD4-258-3.0-1400-C 2.58 0.1016 3.0 14 38
3640-000339 GD4-259-3.0-1400-C 2.59 0.102 3.0 14 38
3640-000340 GD4-260-3.0-1400-C 2.60 0.1024 3.0 14 38
3640-000341 GD4-261-3.0-1400-C 2.61 0.1028 3.0 14 38
3640-000342 GD4-262-3.0-1400-C 2.62 0.1031 3.0 14 38
3640-000343 GD4-263-3.0-1400-C 2.63 0.1035 3.0 14 38
3640-000344 GD4-264-3.0-1400-C 2.64 0.1039 3.0 14 38
3640-000345 GD4-265-3.0-1400-C 2.65 0.1043 3.0 14 38
3640-000346 GD4-266-3.0-1400-C 2.66 0.1047 3.0 14 38
3640-000347 GD4-267-3.0-1400-C 2.67 0.1051 3.0 14 38
3640-000348 GD4-268-3.0-1400-C 2.68 0.1055 3.0 14 38
3640-000349 GD4-269-3.0-1400-C 2.69 0.1059 3.0 14 38
3640-000350 GD4-270-3.0-1400-C 2.70 0.1063 3.0 14 38
3640-000351 GD4-271-3.0-1400-C 2.71 0.1067 3.0 14 38
3640-000352 GD4-272-3.0-1400-C 2.72 0.1071 3.0 14 38
3640-000353 GD4-273-3.0-1400-C 2.73 0.1075 3.0 14 38
3640-000354 GD4-274-3.0-1400-C 2.74 0.1079 3.0 14 38
3640-000355 GD4-275-3.0-1400-C 2.75 0.1083 3.0 14 38
3640-000356 GD4-276-3.0-1400-C 2.76 0.1087 3.0 14 38
3640-000357 GD4-277-3.0-1400-C 2.77 0.1091 3.0 14 38
3640-000358 GD4-278-3.0-1400-C 2.78 0.1094 3.0 14 38
3640-000359 GD4-279-3.0-1400-C 2.79 0.1098 3.0 14 38
3640-000360 GD4-280-3.0-1400-C 2.80 0.1102 3.0 14 38
3640-000361 GD4-281-3.0-1400-C 2.81 0.1106 3.0 14 38
3640-000362 GD4-282-3.0-1400-C 2.82 0.1110 3.0 14 38
3640-000363 GD4-283-3.0-1400-C 2.83 0.1114 3.0 14 38
3640-000364 GD4-284-3.0-1400-C 2.84 0.1118 3.0 14 38
3640-000365 GD4-285-3.0-1400-C 2.85 0.1122 3.0 14 38
3640-000366 GD4-286-3.0-1400-C 2.86 0.1126 3.0 14 38
3640-000367 GD4-287-3.0-1400-C 2.87 0.1130 3.0 14 38
3640-000368 GD4-288-3.0-1400-C 2.88 0.1134 3.0 14 38
3640-000369 GD4-289-3.0-1400-C 2.89 0.1138 3.0 14 38
3640-000370 GD4-290-3.0-1400-C 2.90 0.1142 3.0 14 38
3640-000371 GD4-291-3.0-1400-C 2.91 0.1146 3.0 14 38
3640-000372 GD4-292-3.0-1400-C 2.92 0.1150 3.0 14 38
3640-000373 GD4-293-3.0-1400-C 2.93 0.1154 3.0 14 38
3640-000374 GD4-294-3.0-1400-C 2.94 0.1157 3.0 14 38
3640-000375 GD4-295-3.0-1400-C 2.95 0.1161 3.0 14 38
3640-000376 GD4-296-3.0-1400-C 2.96 0.1165 3.0 14 38
3640-000377 GD4-297-3.0-1400-C 2.97 0.1169 3.0 14 38
3640-000378 GD4-298-3.0-1400-C 2.98 0.1173 3.0 14 38
3640-000379 GD4-299-3.0-1400-C 2.99 0.1177 3.0 14 38
3640-000380 GD4-300-3.0-1400-C 3.00 0.1181 3.0 14 38

3650

3650 Series

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3650 Solid Carbide 5-7 X Dia 140° 35° 2 h6 (+0.000 -0.006mm) No

Click Below To Expand

Drill Ø .1mm - 1.27mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3650-000100 GD5-010-1.0-050-C 0.10 0.0039 1.0 0.5 25
3650-000101 GD5-011-1.0-050-C 0.11 0.0043 1.0 0.5 25
3650-000102 GD5-012-1.0-050-C 0.12 0.0047 1.0 0.5 25
3650-000103 GD5-013-1.0-060-C 0.13 0.0051 1.0 0.6 25
3650-000104 GD5-014-1.0-070-C 0.14 0.0055 1.0 0.7 25
3650-000105 GD5-015-1.0-100-C 0.15 0.0059 1.0 1.0 25
3650-000106 GD5-016-1.0-100-C 0.16 0.0063 1.0 1.0 25
3650-000107 GD5-017-1.0-100-C 0.17 0.0067 1.0 1.0 25
3650-000108 GD5-018-1.0-100-C 0.18 0.0071 1.0 1.0 25
3650-000109 GD5-019-1.0-100-C 0.19 0.0075 1.0 1.0 25
3650-000110 GD5-020-1.0-180-C 0.20 0.0079 1.0 1.8 25
3650-000111 GD5-021-1.0-180-C 0.21 0.0083 1.0 1.8 25
3650-000112 GD5-022-1.0-180-C 0.22 0.0087 1.0 1.8 25
3650-000113 GD5-023-1.0-180-C 0.23 0.0091 1.0 1.8 25
3650-000114 GD5-024-1.0-180-C 0.24 0.0094 1.0 1.8 25
3650-000115 GD5-025-1.0-220-C 0.25 0.0098 1.0 2.2 25
3650-000116 GD5-026-1.0-220-C 0.26 0.0102 1.0 2.2 25
3650-000117 GD5-027-1.0-220-C 0.27 0.0106 1.0 2.2 25
3650-000118 GD5-028-1.0-220-C 0.28 0.0110 1.0 2.2 25
3650-000119 GD5-029-1.0-220-C 0.29 0.0114 1.0 2.2 25
3650-000120 GD5-030-1.0-220-C 0.30 0.0118 1.0 2.2 25
3650-000121 GD5-031-1.0-280-C 0.31 0.0122 1.0 2.8 25
3650-000122 GD5-032-1.0-280-C 0.32 0.0126 1.0 2.8 25
3650-000123 GD5-033-1.0-280-C 0.33 0.0130 1.0 2.8 25
3650-000124 GD5-034-1.0-280-C 0.34 0.0134 1.00 2.8 25
3650-000125 GD5-035-1.0-280-C 0.35 0.0138 1.0 2.8 25
3650-000126 GD5-036-1.0-280-C 0.36 0.0142 1.0 2.8 25
3650-000127 GD5-037-1.0-280-C 0.37 0.0146 1.0 2.8 25
3650-000128 GD5-038-1.0-280-C 0.38 0.0150 1.0 2.8 25
3650-000129 GD5-039-1.0-360-C 0.39 0.0154 1.0 3.6 25
3650-000130 GD5-040-1.0-360-C 0.40 0.0157 1.0 3.6 25
3650-000131 GD5-041-1.0-360-C 0.41 0.0161 1.0 3.6 25
3650-000132 GD5-042-1.0-360-C 0.42 0.0165 1.0 3.6 25
3650-000133 GD5-043-1.0-360-C 0.43 0.0169 1.0 3.6 25
3650-000134 GD5-044-1.0-360-C 0.44 0.0173 1.0 3.6 25
3650-000135 GD5-045-1.0-360-C 0.45 0.0177 1.0 3.6 25
3650-000136 GD5-046-1.0-360-C 0.46 0.0181 1.0 3.6 25
3650-000137 GD5-047-1.0-360-C 0.47 0.0185 1.0 3.6 25
3650-000138 GD5-048-1.0-360-C 0.48 0.0189 1.0 3.6 25
3650-000139 GD5-049-1.0-400-C 0.49 0.0193 1.0 4.0 25
3650-000140 GD5-050-1.0-400-C 0.50 0.0197 1.0 4.0 25
3650-000141 GD5-051-1.0-400-C 0.51 0.0201 1.0 4.0 25
3650-000142 GD5-052-1.0-400-C 0.52 0.0205 1.0 4.0 25
3650-000143 GD5-053-1.0-400-C 0.53 0.0209 1.0 4.0 25
3650-000144 GD5-054-1.0-400-C 0.54 0.0213 1.0 4.0 25
3650-000145 GD5-055-1.0-450-C 0.55 0.0217 1.0 4.5 25
3650-000146 GD5-056-1.0-450-C 0.56 0.0220 1.0 4.5 25
3650-000147 GD5-057-1.0-450-C 0.57 0.0224 1.0 4.5 25
3650-000148 GD5-058-1.0-450-C 0.58 0.0228 1.0 4.5 25
3650-000149 GD5-059-1.0-450-C 0.59 0.0232 1.0 4.5 25
3650-000150 GD5-060-1.5-450-C 0.60 0.0236 1.5 4.5 30
3650-000151 GD5-061-1.5-500-C 0.61 0.024 1.5 5.0 30
3650-000152 GD5-062-1.5-500-C 0.62 0.0244 1.5 5.0 30
3650-000153 GD5-063-1.5-500-C 0.63 0.0248 1.5 5.0 30
3650-000154 GD5-064-1.5-500-C 0.64 0.0252 1.5 5.0 30
3650-000155 GD5-065-1.5-500-C 0.65 0.0256 1.5 5.0 30
3650-000156 GD5-066-1.5-500-C 0.66 0.0260 1.5 5.0 30
3650-000157 GD5-067-1.5-500-C 0.67 0.0264 1.5 5.0 30
3650-000158 GD5-068-1.5-500-C 0.68 0.0268 1.5 5.0 30
3650-000159 GD5-069-1.5-560-C 0.69 0.0272 1.5 5.6 30
3650-000160 GD5-070-1.5-560-C 0.70 0.0276 1.5 5.6 30
3650-000161 GD5-071-1.5-560-C 0.71 0.0280 1.5 5.6 30
3650-000162 GD5-072-1.5-560-C 0.72 0.0283 1.5 5.6 30
3650-000163 GD5-073-1.5-560-C 0.73 0.0287 1.5 5.6 30
3650-000164 GD5-074-1.5-560-C 0.74 0.0291 1.5 5.6 30
3650-000165 GD5-075-1.5-560-C 0.75 0.0295 1.5 5.6 30
3650-000166 GD5-076-1.5-630-C 0.76 0.0299 1.5 6.3 30
3650-000167 GD5-077-1.5-630-C 0.77 0.0303 1.5 6.3 30
3650-000168 GD5-078-1.5-630-C 0.78 0.0307 1.5 6.3 30
3650-000169 GD5-079-1.5-630-C 0.79 0.0311 1.5 6.3 30
3650-000170 GD5-080-1.5-630-C 0.80 0.0315 1.5 6.3 30
3650-000171 GD5-081-1.5-630-C 0.81 0.0319 1.5 6.3 30
3650-000172 GD5-082-1.5-630-C 0.82 0.0323 1.5 6.3 30
3650-000173 GD5-083-1.5-630-C 0.83 0.0327 1.5 6.3 30
3650-000174 GD5-084-1.5-630-C 0.84 0.0331 1.5 6.3 30
3650-000175 GD5-085-1.5-630-C 0.85 0.0335 1.5 6.3 30
3650-000176 GD5-086-1.5-710-C 0.86 0.0339 1.5 7.1 30
3650-000177 GD5-087-1.5-710-C 0.87 0.0343 1.5 7.1 30
3650-000178 GD5-088-1.5-710-C 0.88 0.0346 1.5 7.1 30
3650-000179 GD5-089-1.5-710-C 0.89 0.035 1.5 7.1 30
3650-000180 GD5-090-1.5-710-C 0.90 0.0354 1.5 7.1 30
3650-000181 GD5-091-1.5-710-C 0.91 0.0358 1.5 7.1 30
3650-000182 GD5-092-1.5-710-C 0.92 0.0362 1.5 7.1 30
3650-000183 GD5-093-1.5-710-C 0.93 0.0366 1.5 7.1 30
3650-000184 GD5-094-1.5-710-C 0.94 0.0370 1.5 7.1 30
3650-000185 GD5-095-1.5-710-C 0.95 0.0374 1.5 7.1 30
3650-000186 GD5-096-1.5-800-C 0.96 0.0378 1.5 8 30
3650-000187 GD5-097-1.5-800-C 0.97 0.0382 1.5 8 30
3650-000188 GD5-098-1.5-800-C 0.98 0.0386 1.5 8 30
3650-000189 GD5-099-1.5-800-C 0.99 0.039 1.5 8 30
3650-000190 GD5-100-1.5-800-C 1.00 0.0394 1.5 8 30
3650-000191 GD5-101-1.5-800-C 1.01 0.0398 1.5 8 30
3650-000192 GD5-102-1.5-800-C 1.02 0.0402 1.5 8 30
3650-000193 GD5-103-1.5-800-C 1.03 0.0406 1.5 8 30
3650-000194 GD5-104-1.5-800-C 1.04 0.0409 1.5 8 30
3650-000195 GD5-105-1.5-800-C 1.05 0.0413 1.5 8 30
3650-000196 GD5-106-1.5-900-C 1.06 0.0417 1.5 9 30
3650-000197 GD5-107-1.5-900-C 1.07 0.0421 1.5 9 30
3650-000198 GD5-108-1.5-900-C 1.08 0.0425 1.5 9 30
3650-000199 GD5-109-1.5-900-C 1.09 0.0429 1.5 9 30
3650-000200 GD5-110-1.5-900-C 1.10 0.0433 1.5 9 30
3650-000201 GD5-111-1.5-900-C 1.11 0.0437 1.5 9 30
3650-000202 GD5-112-1.5-900-C 1.12 0.0441 1.5 9 30
3650-000203 GD5-113-1.5-900-C 1.13 0.0445 1.5 9 30
3650-000204 GD5-114-1.5-900-C 1.14 0.0449 1.5 9 30
3650-000205 GD5-115-1.5-900-C 1.15 0.0453 1.5 9 30
3650-000206 GD5-116-1.5-1000-C 1.16 0.0457 1.5 10 30
3650-000207 GD5-117-1.5-1000-C 1.17 0.0461 1.5 10 30
3650-000208 GD5-118-1.5-1000-C 1.18 0.0465 1.5 10 30
3650-000209 GD5-119-1.5-1000-C 1.19 0.0469 1.5 10 30
3650-000210 GD5-120-1.5-1000-C 1.20 0.0472 1.5 10 30
3650-000211 GD5-121-1.5-1000-C 1.21 0.0476 1.5 10 30
3650-000212 GD5-122-1.5-1000-C 1.22 0.0480 1.5 10 30
3650-000213 GD5-123-1.5-1000-C 1.23 0.0484 1.5 10 30
3650-000214 GD5-124-1.5-1000-C 1.24 0.0488 1.5 10 30
3650-000215 GD5-125-1.5-1000-C 1.25 0.0492 1.5 10 30
3650-000216 GD5-126-1.5-1000-C 1.26 0.0496 1.5 10 30
3650-000217 GD5-127-1.5-1000-C 1.27 0.0500 1.5 10 30
Drill Ø 1.28mm - 2.99mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3650-000218 GD5-128-1.5-1000-C 1.28 0.0504 1.5 10 30
3650-000219 GD5-129-1.5-1000-C 1.29 0.0508 1.5 10 30
3650-000220 GD5-130-1.5-1000-C 1.3 0.0512 1.5 10 30
3650-000221 GD5-131-1.5-1120-C 1.31 0.0516 1.5 11.2 30
3650-000222 GD5-132-1.5-1120-C 1.32 0.052 1.5 11.2 30
3650-000223 GD5-133-1.5-1120-C 1.33 0.0524 1.5 11.2 30
3650-000224 GD5-134-1.5-1120-C 1.34 0.0528 1.5 11.2 30
3650-000225 GD5-135-1.5-1120-C 1.35 0.0531 1.5 11.2 30
3650-000226 GD5-136-1.5-1120-C 1.36 0.0535 1.5 11.2 30
3650-000227 GD5-137-1.5-1120-C 1.37 0.0539 1.5 11.2 30
3650-000228 GD5-138-1.5-1120-C 1.38 0.0543 1.5 11.2 30
3650-000229 GD5-139-1.5-1120-C 1.39 0.0547 1.5 11.2 30
3650-000230 GD5-140-1.5-1120-C 1.4 0.0551 1.5 11.2 30
3650-000231 GD5-141-1.5-1120-C 1.41 0.0555 1.5 11.2 30
3650-000232 GD5-142-1.5-1120-C 1.42 0.0559 1.5 11.2 30
3650-000233 GD5-143-1.5-1120-C 1.43 0.0563 1.5 11.2 30
3650-000234 GD5-144-1.5-1120-C 1.44 0.0567 1.5 11.2 30
3650-000235 GD5-145-1.5-1120-C 1.45 0.0571 1.5 11.2 30
3650-000236 GD5-146-1.5-1120-C 1.46 0.0575 1.5 11.2 30
3650-000237 GD5-147-1.5-1120-C 1.47 0.0579 1.5 11.2 30
3650-000238 GD5-148-1.5-1120-C 1.48 0.0583 1.5 11.2 30
3650-000239 GD5-149-1.5-1120-C 1.49 0.0587 1.5 11.2 30
3650-000240 GD5-150-200-1200-C 1.5 0.0591 2 12 38
3650-000241 GD5-151-200-1200-C 1.51 0.0594 2 12 38
3650-000242 GD5-152-200-1200-C 1.52 0.0598 2 12 38
3650-000243 GD5-153-200-1200-C 1.53 0.0602 2 12 38
3650-000244 GD5-154-200-1200-C 1.54 0.0606 2 12 38
3650-000245 GD5-155-200-1200-C 1.55 0.061 2 12 38
3650-000246 GD5-156-200-1200-C 1.56 0.0614 2 12 38
3650-000247 GD5-157-200-1200-C 1.57 0.0618 2 12 38
3650-000248 GD5-158-200-1200-C 1.58 0.0622 2 12 38
3650-000249 GD5-159-200-1200-C 1.59 0.0626 2 12 38
3650-000250 GD5-160-200-1200-C 1.6 0.063 2 12 38
3650-000251 GD5-161-200-1200-C 1.61 0.0634 2 12 38
3650-000252 GD5-162-200-1200-C 1.62 0.0638 2 12 38
3650-000253 GD5-163-200-1200-C 1.63 0.0642 2 12 38
3650-000254 GD5-164-200-1200-C 1.64 0.0646 2 12 38
3650-000255 GD5-165-200-1200-C 1.65 0.065 2 12 38
3650-000256 GD5-166-200-1200-C 1.66 0.0654 2 12 38
3650-000257 GD5-167-200-1200-C 1.67 0.0657 2 12 38
3650-000258 GD5-168-200-1200-C 1.68 0.0661 2 12 38
3650-000259 GD5-169-200-1200-C 1.69 0.0665 2 12 38
3650-000260 GD5-170-200-1200-C 1.7 0.0669 2 12 38
3650-000261 GD5-171-200-1200-C 1.71 0.0673 2 12 38
3650-000262 GD5-172-200-1200-C 1.72 0.0677 2 12 38
3650-000263 GD5-173-200-1200-C 1.73 0.0681 2 12 38
3650-000264 GD5-174-200-1200-C 1.74 0.0685 2 12 38
3650-000265 GD5-175-200-1200-C 1.75 0.0689 2 12 38
3650-000266 GD5-176-200-1200-C 1.76 0.0693 2 12 38
3650-000267 GD5-177-200-1200-C 1.77 0.0697 2 12 38
3650-000268 GD5-178-200-1200-C 1.78 0.0701 2 12 38
3650-000269 GD5-179-200-1200-C 1.79 0.0705 2 12 38
3650-000270 GD5-180-200-1200-C 1.8 0.0709 2 12 38
3650-000271 GD5-181-200-1200-C 1.81 0.0713 2 12 38
3650-000272 GD5-182-200-1200-C 1.82 0.0717 2 12 38
3650-000273 GD5-183-200-1200-C 1.83 0.072 2 12 38
3650-000274 GD5-184-200-1200-C 1.84 0.0724 2 12 38
3650-000275 GD5-185-200-1200-C 1.85 0.0728 2 12 38
3650-000276 GD5-186-200-1200-C 1.86 0.0732 2 12 38
3650-000277 GD5-187-200-1200-C 1.87 0.0736 2 12 38
3650-000278 GD5-188-200-1200-C 1.88 0.074 2 12 38
3650-000279 GD5-189-200-1200-C 1.89 0.0744 2 12 38
3650-000280 GD5-190-200-1200-C 1.9 0.0748 2 12 38
3650-000281 GD5-191-200-1200-C 1.91 0.0752 2 12 38
3650-000282 GD5-192-200-1200-C 1.92 0.0756 2 12 38
3650-000283 GD5-193-200-1200-C 1.93 0.076 2 12 38
3650-000284 GD5-194-200-1200-C 1.94 0.0764 2 12 38
3650-000285 GD5-195-200-1200-C 1.95 0.0768 2 12 38
3650-000286 GD5-196-200-1200-C 1.96 0.0772 2 12 38
3650-000287 GD5-197-200-1200-C 1.97 0.0776 2 12 38
3650-000288 GD5-198-200-1200-C 1.98 0.078 2 12 38
3650-000289 GD5-199-200-1200-C 1.99 0.0783 2 12 38

3660

3660 Series

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3660 Solid Carbide 6-7 X Dia 140° 30° 2 h4 (+0.000 -0.003mm) No

Click Below To Expand

Drill Ø 0.5mm - 3.00mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length I2 D Length OAL (mm)
3660-000100 GD6-050-3.0-440-C 0.50 0.0197 3.0 3.5 4.4 50
3660-000101 GD6-055-3.0-500-C 0.55 0.0217 3.0 4.0 5.0 50
3660-000102 GD6-060-3.0-560-C 0.60 0.0236 3.0 4.5 5.6 50
3660-000103 GD6-065-3.0-630-C 0.65 0.0256 3.0 5.0 6.3 50
3660-000104 GD6-070-3.0-630-C 0.70 0.0276 3.0 5.0 6.3 50
3660-000105 GD6-075-3.0-690-C 0.75 0.0295 3.0 5.5 6.9 50
3660-000106 GD6-080-3.0-720-C 0.80 0.0315 3.0 5.6 7.2 50
3660-000107 GD6-085-3.0-760-C 0.85 0.0335 3.0 6.0 7.6 50
3660-000108 GD6-090-3.0-810-C 0.90 0.0354 3.0 6.5 8.1 50
3660-000109 GD6-095-3.0-850-C 0.95 0.0374 3.0 6.7 8.5 50
3660-000110 GD6-100-3.0-880-C 1.00 0.0394 3.0 7.0 8.8 50
3660-000111 GD6-105-3.0-940-C 1.05 0.0413 3.0 7.5 9.4 50
3660-000112 GD6-110-3.0-101-C 1.10 0.0433 3.0 8.0 10.1 50
3660-000113 GD6-115-3.0-104-C 1.15 0.0453 3.0 8.1 10.4 50
3660-000114 GD6-120-3.0-110-C 1.20 0.0472 3.0 8.5 11 50
3660-000115 GD6-125-3.0-113-C 1.25 0.0492 3.0 8.9 11.3 50
3660-000116 GD6-130-3.0-117-C 1.30 0.0512 3.0 9.2 11.7 50
3660-000117 GD6-135-3.0-122-C 1.35 0.0531 3.0 9.6 12.2 50
3660-000118 GD6-140-3.0-125-C 1.40 0.0551 3.0 10 12.5 50
3660-000119 GD6-145-3.0-130-C 1.45 0.0571 3.0 10.5 13 50
3660-000120 GD6-150-3.0-130-C 1.50 0.0591 3.0 10.5 13 50
3660-000121 GD6-155-3.0-135-C 1.55 0.061 3.0 11.0 13.5 50
3660-000122 GD6-160-3.0-140-C 1.60 0.063 3.0 11.5 14 50
3660-000123 GD6-165-3.0-150-C 1.65 0.065 3.0 12 15 50
3660-000124 GD6-170-3.0-150-C 1.70 0.0669 3.0 12 15 50
3660-000125 GD6-175-3.0-155-C 1.75 0.0689 3.0 12.5 15.5 50
3660-000126 GD6-180-3.0-160-C 1.80 0.0709 3.0 13 16 50
3660-000127 GD6-185-3.0-160-C 1.85 0.0728 3.0 13 16 50
3660-000128 GD6-190-3.0-175-C 1.90 0.0748 3.0 13.5 17.5 50
3660-000129 GD6-195-3.0-180-C 1.95 0.0768 3.0 14 18 50
3660-000130 GD6-200-3.0-180-C 2.00 0.0787 3.0 14 18 50
3660-000131 GD6-205-3.0-185-C 2.05 0.0807 3.0 14.5 18.5 50
3660-000132 GD6-210-3.0-190-C 2.10 0.0827 3.0 15 19 50
3660-000133 GD6-215-3.0-190-C 2.15 0.0846 3.0 15 19 50
3660-000134 GD6-220-3.0-200-C 2.20 0.0866 3.0 16 20 50
3660-000135 GD6-225-3.0-200-C 2.25 0.0886 3.0 16 20 50
3660-000136 GD6-230-3.0-210-C 2.30 0.0906 3.0 16.5 21 50
3660-000137 GD6-235-3.0-210-C 2.35 0.0925 3.0 16.5 21 50
3660-000138 GD6-240-3.0-220-C 2.40 0.0945 3.0 17 22 50
3660-000139 GD6-245-3.0-225-C 2.45 0.0965 3.0 17.5 22.5 50
3660-000140 GD6-250-3.0-230-C 2.50 0.0984 3.0 18 23 50
3660-000141 GD6-255-3.0-230-C 2.55 0.1004 3.0 18 23 50
3660-000142 GD6-260-3.0-235-C 2.60 0.1024 3.0 18.5 23.5 50
3660-000143 GD6-265-3.0-235-C 2.65 0.1043 3.0 18.5 23.5 50
3660-000144 GD6-270-3.0-240-C 2.70 0.1063 3.0 19 24 50
3660-000145 GD6-275-3.0-240-C 2.75 0.1083 3.0 19 24 50
3660-000146 GD6-280-3.0-250-C 2.80 0.1102 3.0 20 25 50
3660-000147 GD6-285-3.0-250-C 2.85 0.1122 3.0 20 25 50
3660-000148 GD6-290-3.0-260-C 2.90 0.1142 3.0 21 26 50
3660-000149 GD6-295-3.0-260-C 2.95 0.1161 3.0 21 26 50
3660-000150 GD6-300-3.0-260C 3.00 0.1181 3.0 21 26 50

3670

3670 Series

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3670 Solid Carbide 12 X Dia 140° 30° 2 h5 (+0.000 -0.004mm) No

Click Below To Expand

Drill Ø 0.5mm - 2.0mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length I2 D Length OAL (mm)
3670-000101 GD7-050-3.0-600-C 0.50 0.0197 3.0 6.00 7.20 50
3670-000103 GD7-055-3.0-660-C 0.55 0.0217 3.0 6.60 7.92 50
3670-000104 GD7-060-3.0-720-C 0.60 0.0236 3.0 7.20 8.64 50
3670-000105 GD7-065-3.0-780-C 0.65 0.0256 3.0 7.80 9.36 50
3670-000106 GD7-070-3.0-840-C 0.70 0.0276 3.0 8.40 10.08 50
3670-000107 GD7-075-3.0-900-C 0.75 0.0295 3.0 9.00 10.80 50
3670-000108 GD7-080-3.0-960-C 0.80 0.0315 3.0 9.60 11.52 50
3670-000109 GD7-085-3.0-1020-C 0.85 0.0335 3.0 10.20 12.24 50
3670-000110 GD7-090-3.0-1080-C 0.90 0.0354 3.0 10.80 12.96 50
3670-000111 GD7-095-3.0-1140-C 0.95 0.0374 3.0 11.40 13.68 50
3670-000112 GD7-100-3.0-1200-C 1.00 0.0394 3.0 12.00 14.40 50
3670-000113 GD7-105-3.0-1260-C 1.05 0.0413 3.0 12.60 15.12 50
3670-000114 GD7-110-3.0-1320-C 1.10 0.0433 3.0 13.20 15.84 50
3670-000115 GD7-115-3.0-1380-C 1.15 0.0453 3.0 13.80 16.56 50
3670-000116 GD7-120-3.0-1440-C 1.20 0.0472 3.0 14.40 17.28 50
3670-000117 GD7-125-3.0-1500-C 1.25 0.0492 3.0 15.00 18.00 50
3670-000118 GD7-130-3.0-1560-C 1.30 0.0512 3.0 15.60 18.72 50
3670-000102 GD7-135-3.0-1620-C 1.35 0.0531 3.0 16.20 19.44 50
3670-000119 GD7-140-3.0-1680-C 1.40 0.0551 3.0 16.80 20.16 50
3670-000120 GD7-145-3.0-1740-C 1.45 0.0571 3.0 17.40 20.88 50
3670-000121 GD7-150-3.0-1800-C 1.50 0.0591 3.0 18.00 21.60 50
3670-000122 GD7-155-3.0-1860-C 1.55 0.0610 3.0 18.60 22.32 60
3670-000123 GD7-160-3.0-1920-C 1.60 0.0630 3.0 19.20 23.04 60
3670-000124 GD7-165-3.0-1980-C 1.65 0.0650 3.0 19.80 23.76 60
3670-000125 GD7-170-3.0-2040-C 1.70 0.0669 3.0 20.40 24.48 60
3670-000126 GD7-175-3.0-2100-C 1.75 0.0689 3.0 21.00 25.20 60
3670-000127 GD7-180-3.0-2160-C 1.80 0.0709 3.0 21.60 25.92 60
3670-000128 GD7-185-3.0-2220-C 1.85 0.0728 3.0 22.20 26.64 60
3670-000129 GD7-190-3.0-2280-C 1.90 0.0748 3.0 22.80 27.36 60
3670-000130 GD7-195-3.0-2340-C 1.95 0.0768 3.0 23.40 28.08 60
3670-000131 GD7-200-3.0-2400-C 2.00 0.0787 3.0 24.00 28.80 60

3680

3680 Series

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3680 Solid Carbide 4-5 X Dia 120° 24° 2 h6 (+0.000 -0.006mm) No

Click Below To Expand

Drill Ø 0.2mm - 1.00mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3680-000100 GD8-020-3.0-110-C 0.20 0.0079 3.0 1.10 38
3680-000101 GD8-021-3.0-110-C 0.21 0.0083 3.0 1.10 38
3680-000102 GD8-022-3.0-110-C 0.22 0.0087 3.0 1.10 38
3680-000103 GD8-023-3.0-110-C 0.23 0.0091 3.0 1.10 38
3680-000104 GD8-024-3.0-110-C 0.24 0.0094 3.0 1.10 38
3680-000105 GD8-025-3.0-130-C 0.25 0.0098 3.0 1.30 38
3680-000106 GD8-026-3.0-130-C 0.26 0.0102 3.0 1.30 38
3680-000107 GD8-027-3.0-130-C 0.27 0.0106 3.0 1.30 38
3680-000108 GD8-028-3.0-130-C 0.28 0.0110 3.0 1.30 38
3680-000109 GD8-029-3.0-130-C 0.29 0.0114 3.0 1.30 38
3680-000110 GD8-030-3.0-160-C 0.30 0.0118 3.0 1.60 38
3680-000111 GD8-031-3.0-160-C 0.31 0.0122 3.0 1.60 38
3680-000112 GD8-032-3.0-160-C 0.32 0.0126 3.0 1.60 38
3680-000113 GD8-033-3.0-160-C 0.33 0.0130 3.0 1.60 38
3680-000114 GD8-034-3.0-160-C 0.34 0.0134 3.0 1.60 38
3680-000115 GD8-035-3.0-160-C 0.35 0.0138 3.0 1.60 38
3680-000116 GD8-036-3.0-160-C 0.36 0.0142 3.0 1.60 38
3680-000117 GD8-037-3.0-160-C 0.37 0.0146 3.0 1.60 38
3680-000118 GD8-038-3.0-160-C 0.38 0.0150 3.0 1.60 38
3680-000119 GD8-039-3.0-200-C 0.39 0.0154 3.0 2.00 38
3680-000120 GD8-040-3.0-200-C 0.40 0.0157 3.0 2.00 38
3680-000121 GD8-041-3.0-200-C 0.41 0.0161 3.0 2.00 38
3680-000122 GD8-042-3.0-200-C 0.42 0.0165 3.0 2.00 38
3680-000123 GD8-043-3.0-200-C 0.43 0.0169 3.0 2.00 38
3680-000124 GD8-044-3.0-200-C 0.44 0.0173 3.0 2.00 38
3680-000125 GD8-045-3.0-200-C 0.45 0.0177 3.0 2.00 38
3680-000126 GD8-046-3.0-200-C 0.46 0.0181 3.0 2.00 38
3680-000127 GD8-047-3.0-200-C 0.47 0.0185 3.0 2.00 38
3680-000128 GD8-048-3.0-200-C 0.48 0.0189 3.0 2.00 38
3680-000129 GD8-049-3.0-200-C 0.49 0.0193 3.0 2.00 38
3680-000130 GD8-050-3.0-240-C 0.50 0.0197 3.0 2.40 38
3680-000131 GD8-051-3.0-240-C 0.51 0.0201 3.0 2.40 38
3680-000132 GD8-052-3.0-240-C 0.52 0.0205 3.0 2.40 38
3680-000133 GD8-053-3.0-240-C 0.53 0.0209 3.0 2.40 38
3680-000134 GD8-054-3.0-280-C 0.54 0.0213 3.0 2.80 38
3680-000135 GD8-055-3.0-280-C 0.55 0.0217 3.0 2.80 38
3680-000136 GD8-056-3.0-280-C 0.56 0.0220 3.0 2.80 38
3680-000137 GD8-057-3.0-280-C 0.57 0.0224 3.0 2.80 38
3680-000138 GD8-058-3.0-280-C 0.58 0.0228 3.0 2.80 38
3680-000139 GD8-059-3.0-280-C 0.59 0.0232 3.0 2.80 38
3680-000140 GD8-060-3.0-280-C 0.60 0.0236 3.0 2.80 38
3680-000141 GD8-061-3.0-330-C 0.61 0.0240 3.0 3.30 38
3680-000142 GD8-062-3.0-330-C 0.62 0.0244 3.0 3.30 38
3680-000143 GD8-063-3.0-330-C 0.63 0.0248 3.0 3.30 38
3680-000144 GD8-064-3.0-330-C 0.64 0.0252 3.0 3.30 38
3680-000145 GD8-065-3.0-330-C 0.65 0.0256 3.0 3.30 38
3680-000146 GD8-066-3.0-330-C 0.66 0.0260 3.0 3.30 38
3680-000147 GD8-067-3.0-330-C 0.67 0.0264 3.0 3.30 38
3680-000148 GD8-068-3.0-380-C 0.68 0.0268 3.0 3.80 38
3680-000149 GD8-069-3.0-380-C 0.69 0.0272 3.0 3.80 38
3680-000150 GD8-070-3.0-380-C 0.70 0.0276 3.0 3.80 38
3680-000151 GD8-071-3.0-380-C 0.71 0.0280 3.0 3.80 38
3680-000152 GD8-072-3.0-380-C 0.72 0.0283 3.0 3.80 38
3680-000153 GD8-073-3.0-380-C 0.73 0.0287 3.0 3.80 38
3680-000154 GD8-074-3.0-380-C 0.74 0.0291 3.0 3.80 38
3680-000155 GD8-075-3.0-380-C 0.75 0.0295 3.0 3.80 38
3680-000156 GD8-076-3.0-420-C 0.76 0.0299 3.0 4.20 38
3680-000157 GD8-077-3.0-420-C 0.77 0.0303 3.0 4.20 38
3680-000158 GD8-078-3.0-420-C 0.78 0.0307 3.0 4.20 38
3680-000159 GD8-079-3.0-420-C 0.79 0.0311 3.0 4.20 38
3680-000160 GD8-080-3.0-440-C 0.80 0.0315 3.0 4.40 38
3680-000161 GD8-081-3.0-440-C 0.81 0.0319 3.0 4.40 38
3680-000162 GD8-082-3.0-440-C 0.82 0.0323 3.0 4.40 38
3680-000163 GD8-083-3.0-440-C 0.83 0.0327 3.0 4.40 38
3680-000164 GD8-084-3.0-440-C 0.84 0.0331 3.0 4.40 38
3680-000165 GD8-085-3.0-440-C 0.85 0.0335 3.0 4.40 38
3680-000166 GD8-086-3.0-480-C 0.86 0.0339 3.0 4.80 38
3680-000167 GD8-087-3.0-480-C 0.87 0.0343 3.0 4.80 38
3680-000168 GD8-088-3.0-480-C 0.88 0.0346 3.0 4.80 38
3680-000169 GD8-089-3.0-480-C 0.89 0.0350 3.0 4.80 38
3680-000170 GD8-090-3.0-480-C 0.90 0.0354 3.0 4.80 38
3680-000171 GD8-091-3.0-480-C 0.91 0.0358 3.0 4.80 38
3680-000172 GD8-092-3.0-480-C 0.92 0.0362 3.0 4.80 38
3680-000173 GD8-093-3.0-480-C 0.93 0.0366 3.0 4.80 38
3680-000174 GD8-094-3.0-480-C 0.94 0.0370 3.0 4.80 38
3680-000175 GD8-095-3.0-480-C 0.95 0.0374 3.0 4.80 38
3680-000176 GD8-096-3.0-480-C 0.96 0.0378 3.0 4.80 38
3680-000177 GD8-097-3.0-480-C 0.97 0.0382 3.0 4.80 38
3680-000178 GD8-098-3.0-480-C 0.98 0.0386 3.0 4.80 38
3680-000179 GD8-099-3.0-480-C 0.99 0.0390 3.0 4.80 38
3680-000180 GD8-100-3.0-480-C 1.00 0.0394 3.0 4.80 38
Drill Ø 1.01mm - 1.60mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3680-000181 GD8-101-3.0-480-C 1.01 0.0398 3.0 4.80 38
3680-000182 GD8-102-3.0-480-C 1.02 0.0402 3.0 4.80 38
3680-000183 GD8-103-3.0-480-C 1.03 0.0406 3.0 4.80 38
3680-000184 GD8-104-3.0-480-C 1.04 0.0409 3.0 4.80 38
3680-000185 GD8-105-3.0-480-C 1.05 0.0413 3.0 4.80 38
3680-000186 GD8-106-3.0-480-C 1.06 0.0417 3.0 4.80 38
3680-000187 GD8-107-3.0-480-C 1.07 0.0421 3.0 4.80 38
3680-000188 GD8-108-3.0-480-C 1.08 0.0425 3.0 4.80 38
3680-000189 GD8-109-3.0-480-C 1.09 0.0429 3.0 4.80 38
3680-000190 GD8-110-3.0-540-C 1.10 0.0433 3.0 5.40 38
3680-000191 GD8-111-3.0-540-C 1.11 0.0437 3.0 5.40 38
3680-000192 GD8-112-3.0-540-C 1.12 0.0441 3.0 5.40 38
3680-000193 GD8-113-3.0-540-C 1.13 0.0445 3.0 5.40 38
3680-000194 GD8-114-3.0-540-C 1.14 0.0449 3.0 5.40 38
3680-000195 GD8-115-3.0-540-C 1.15 0.0453 3.0 5.40 38
3680-000196 GD8-116-3.0-540-C 1.16 0.0457 3.0 5.40 38
3680-000197 GD8-117-3.0-540-C 1.17 0.0461 3.0 5.40 38
3680-000198 GD8-118-3.0-540-C 1.18 0.0465 3.0 5.40 38
3680-000199 GD8-119-3.0-540-C 1.19 0.0469 3.0 5.40 38
3680-000200 GD8-120-3.0-600-C 1.20 0.0472 3.0 6.00 38
3680-000201 GD8-121-3.0-600-C 1.21 0.0476 3.0 6.00 38
3680-000202 GD8-122-3.0-600-C 1.22 0.0480 3.0 6.00 38
3680-000203 GD8-123-3.0-600-C 1.23 0.0484 3.0 6.00 38
3680-000204 GD8-124-3.0-600-C 1.24 0.0488 3.0 6.00 38
3680-000205 GD8-125-3.0-600-C 1.25 0.0492 3.0 6.00 38
3680-000206 GD8-126-3.0-600-C 1.26 0.0496 3.0 6.00 38
3680-000207 GD8-127-3.0-600-C 1.27 0.0500 3.0 6.00 38
3680-000208 GD8-128-3.0-600-C 1.28 0.0504 3.0 6.00 38
3680-000209 GD8-129-3.0-600-C 1.29 0.0508 3.0 6.00 38
3680-000210 GD8-130-3.0-670-C 1.30 0.0512 3.0 6.70 38
3680-000211 GD8-131-3.0-670-C 1.31 0.0516 3.0 6.70 38
3680-000212 GD8-132-3.0-670-C 1.32 0.0520 3.0 6.70 38
3680-000213 GD8-133-3.0-670-C 1.33 0.0524 3.0 6.70 38
3680-000214 GD8-134-3.0-670-C 1.34 0.0528 3.0 6.70 38
3680-000215 GD8-135-3.0-670-C 1.35 0.0531 3.0 6.70 38
3680-000216 GD8-136-3.0-670-C 1.36 0.0535 3.0 6.70 38
3680-000217 GD8-137-3.0-670-C 1.37 0.0539 3.0 6.70 38
3680-000218 GD8-138-3.0-670-C 1.38 0.0543 3.0 6.70 38
3680-000219 GD8-139-3.0-670-C 1.39 0.0547 3.0 6.70 38
3680-000220 GD8-140-3.0-670-C 1.40 0.0551 3.0 6.70 38
3680-000221 GD8-141-3.0-670-C 1.41 0.0555 3.0 6.70 38
3680-000222 GD8-142-3.0-670-C 1.42 0.0559 3.0 6.70 38
3680-000223 GD8-143-3.0-670-C 1.43 0.0563 3.0 6.70 38
3680-000224 GD8-144-3.0-670-C 1.44 0.0567 3.0 6.70 38
3680-000225 GD8-145-3.0-670-C 1.45 0.0571 3.0 6.70 38
3680-000226 GD8-146-3.0-670-C 1.46 0.0575 3.0 6.70 38
3680-000227 GD8-147-3.0-670-C 1.47 0.0579 3.0 6.70 38
3680-000228 GD8-148-3.0-670-C 1.48 0.0583 3.0 6.70 38
3680-000229 GD8-149-3.0-670-C 1.49 0.0587 3.0 6.70 38
3680-000230 GD8-150-3.0-720-C 1.50 0.0591 3.0 7.20 38
3680-000231 GD8-151-3.0-720-C 1.51 0.0594 3.0 7.20 38
3680-000232 GD8-152-3.0-720-C 1.52 0.0598 3.0 7.20 38
3680-000233 GD8-153-3.0-720-C 1.53 0.0602 3.0 7.20 38
3680-000234 GD8-154-3.0-720-C 1.54 0.0606 3.0 7.20 38
3680-000235 GD8-155-3.0-720-C 1.55 0.0610 3.0 7.20 38
3680-000236 GD8-156-3.0-720-C 1.56 0.0614 3.0 7.20 38
3680-000237 GD8-157-3.0-720-C 1.57 0.0618 3.0 7.20 38
3680-000238 GD8-158-3.0-720-C 1.58 0.0622 3.0 7.20 38
3680-000239 GD8-159-3.0-720-C 1.59 0.0626 3.0 7.20 38
3680-000240 GD8-160-3.0-720-C 1.60 0.0630 3.0 7.20 38

3690

3690 Series - Coolant Thru Drills

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3690 Solid Carbide 15 X Dia 140° 30° 2 h5 (+0.000 -0.004mm) Yes

Click Below To Expand

Drill Ø 2.05mm - 3.00mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length OAL (mm)
3690-000100 GD9-205-3.0-034-C 2.05 0.0807 3.00 34 70
3690-000101 GD9-210-3.0-034-C 2.10 0.0827 3.00 34 70
3690-000102 GD9-215-3.0-036-C 2.15 0.0846 3.00 36 70
3690-000103 GD9-220-3.0-036-C 2.20 0.0866 3.00 36 70
3690-000104 GD9-225-3.0-038-C 2.25 0.0886 3.00 38 70
3690-000105 GD9-230-3.0-038-C 2.30 0.0906 3.00 38 70
3690-000106 GD9-235-3.0-040-C 2.35 0.0925 3.00 40 70
3690-000107 GD9-240-3.0-040-C 2.40 0.0945 3.00 40 70
3690-000108 GD9-245-3.0-042-C 2.45 0.0965 3.00 42 70
3690-000109 GD9-250-3.0-042-C 2.50 0.0984 3.00 42 70
3690-000110 GD9-255-3.0-044-C 2.55 0.1004 3.00 44 90
3690-000111 GD9-260-3.0-044-C 2.60 0.1024 3.00 44 90
3690-000112 GD9-265-3.0-046-C 2.65 0.1043 3.00 46 90
3690-000113 GD9-270-3.0-046-C 2.70 0.1063 3.00 46 90
3690-000114 GD9-275-3.0-048-C 2.75 0.1083 3.00 48 90
3690-000115 GD9-280-3.0-048-C 2.80 0.1102 3.00 48 90
3690-000116 GD9-285-3.0-050-C 2.85 0.1122 3.00 50 90
3690-000117 GD9-290-3.0-050-C 2.90 0.1142 3.00 50 90
3690-000118 GD9-295-3.0-050-C 2.95 0.1161 3.00 50 90
3690-000119 GD9-300-3.0-050-C 3.00 0.1181 3.00 50 90

3700

3700 Series - Gun Drills

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3700 Solid Carbide 10 X Dia 120° None Half Round h5 (+0.000 -0.004mm) No

Click Below To Expand

Drill Ø 0.20mm - 3.00mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length (mm) OAL (mm)
3700-000100 GD10-020-1.5-020-C 0.20 0.0079 1.5 2.0 30
3700-000101 GD10-025-1.5-025-C 0.25 0.0098 1.5 2.5 30
3700-000102 GD10-030-1.5-030-C 0.30 0.0118 1.5 3.0 30
3700-000103 GD10-035-1.5-035-C 0.35 0.0138 1.5 3.5 30
3700-000104 GD10-040-1.5-040-C 0.40 0.0157 1.5 4.0 30
3700-000105 GD10-045-1.5-045-C 0.45 0.0177 1.5 4.5 30
3700-000106 GD10-050-1.5-050-C 0.50 0.0197 1.5 5.0 30
3700-000107 GD10-055-1.5-055-C 0.55 0.0217 1.5 5.5 30
3700-000108 GD10-060-1.5-060-C 0.60 0.0236 1.5 6.0 30
3700-000109 GD10-065-1.5-065-C 0.65 0.0256 1.5 6.5 30
3700-000110 GD10-070-1.5-070-C 0.70 0.0276 1.5 7.0 30
3700-000111 GD10-075-1.5-075-C 0.75 0.0295 1.5 7.5 30
3700-000112 GD10-080-1.5-080-C 0.80 0.0315 1.5 8.0 30
3700-000113 GD10-085-1.5-085-C 0.85 0.0335 1.5 8.5 30
3700-000114 GD10-090-1.5-090-C 0.90 0.0354 1.5 9.0 30
3700-000115 GD10-095-1.5-095-C 0.95 0.0374 1.5 9.5 30
3700-000116 GD10-100-1.5-100-C 1.00 0.0394 1.5 10.0 30
3700-000117 GD10-105-1.5-105-C 1.05 0.0413 1.5 10.5 30
3700-000118 GD10-110-1.5-110-C 1.10 0.0433 1.5 11.0 30
3700-000119 GD10-115-1.5-115-C 1.15 0.0453 1.5 11.5 30
3700-000120 GD10-120-1.5-120-C 1.20 0.0472 1.5 12.0 30
3700-000121 GD10-125-1.5-125-C 1.25 0.0492 1.5 12.5 30
3700-000122 GD10-130-1.5-130-C 1.30 0.0512 1.5 13.0 30
3700-000123 GD10-135-1.5-135-C 1.35 0.0531 1.5 13.5 30
3700-000124 GD10-140-1.5-140-C 1.40 0.0551 1.5 14.0 30
3700-000125 GD10-145-1.5-145-C 1.45 0.0571 1.5 14.5 30
3700-000126 GD10-150-2.0-150-C 1.50 0.0591 2.0 15.0 38
3700-000127 GD10-155-2.0-155-C 1.55 0.061 2.0 15.5 38
3700-000128 GD10-160-2.0-160-C 1.60 0.063 2.0 16.0 38
3700-000129 GD10-165-2.0-165-C 1.65 0.065 2.0 16.5 38
3700-000130 GD10-170-2.0-170-C 1.70 0.0669 2.0 17 38
3700-000131 GD10-175-2.0-175-C 1.75 0.0689 2.0 17.5 38
3700-000132 GD10-180-2.0-180-C 1.80 0.0709 2.0 18 38
3700-000133 GD10-185-2.0-185-C 1.85 0.0728 2.0 18.5 38
3700-000134 GD10-190-2.0-190-C 1.9 0.0748 2.0 19 38
3700-000135 GD10-195-2.0-195-C 1.95 0.0768 2.0 19.5 38
3700-000136 GD10-200-3.0-200-C 2.0 0.0787 3.0 20 50
3700-000137 GD10-210-3.0-210-C 2.1 0.0827 3.0 21 50
3700-000138 GD10-220-3.0-220-C 2.2 0.0866 3.0 22 50
3700-000139 GD10-230-3.0-230-C 2.3 0.0906 3.0 23 50
3700-000140 GD10-240-3.0-240-C 2.4 0.0945 3.0 24 50
3700-000141 GD10-250-3.0-250-C 2.5 0.0984 3.0 25 50
3700-000142 GD10-260-3.0-260-C 2.6 0.1024 3.0 26 50
3700-000143 GD10-270-3.0-270-C 2.7 0.1063 3.0 27 50
3700-000144 GD10-280-3.0-280-C 2.8 0.1102 3.0 28 50
3700-000145 GD10-290-3.0-290-C 2.9 0.1142 3.0 29 50
3700-000146 GD10-300-3.0-300-C 3.0 0.1181 3.0 30 50

3710

3710 Series - 3 Flute Short Drills

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3710 Solid Carbide 4-6 X Dia 140° 30° 3 h5 (+0.000 -0.004mm) No

Click Below To Expand

Drill Ø 0.50mm - 1.50mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length (mm) OAL (mm)
3710-000100 GD11-050-3.0-300-C 0.50 0.0197 3.0 3.0 30
3710-000101 GD11-055-3.0-300-C 0.55 0.0217 3.0 3.0 30
3710-000102 GD11-060-3.0-300-C 0.6 0.0236 3.0 3.0 30
3710-000103 GD11-065-3.0-300-C 0.65 0.0256 3.0 3.0 30
3710-000104 GD11-070-3.0-300-C 0.70 0.0276 3.0 3.0 30
3710-000105 GD11-075-3.0-350-C 0.75 0.0295 3.0 3.5 30
3710-000106 GD11-080-3.0-350-C 0.80 0.0315 3.0 3.5 30
3710-000107 GD11-085-3.0-350-C 0.85 0.0335 3.0 3.5 30
3710-000108 GD11-090-3.0-350-C 0.90 0.0354 3.0 3.5 30
3710-000109 GD11-095-3.0-350-C 0.95 0.0374 3.0 3.5 30
3710-000110 GD11-100-3.0-350-C 1.00 0.0394 3.0 3.5 30
3710-000111 GD11-105-3.0-400-C 1.05 0.0413 3.0 4.0 30
3710-000112 GD11-110-3.0-400-C 1.10 0.0433 3.0 4.0 30
3710-000113 GD11-115-3.0-400-C 1.15 0.0453 3.0 4.0 30
3710-000114 GD11-120-3.0-400-C 1.20 0.0472 3.0 4.0 30
3710-000115 GD11-125-3.0-400-C 1.25 0.0492 3.0 4.0 30
3710-000116 GD11-130-3.0-500-C 1.30 0.0512 3.0 5.0 30
3710-000117 GD11-135-3.0-500-C 1.35 0.0531 3.0 5.0 30
3710-000118 GD11-140-3.0-500-C 1.40 0.0551 3.0 5.0 30
3710-000119 GD11-145-3.0-500-C 1.45 0.0571 3.0 5.0 30
3710-000120 GD11-150-3.0-500-C 1.50 0.0591 3.0 5.0 30

3720

3720 Series - 3 Flute Long Drills

Series Material Depth Drill Point Helix # Flutes Tolerance Coolant Thru
3720 Solid Carbide 4-6 X Dia 140° 30° 3 h5 (+0.000 -0.004mm) No

Click Below To Expand

Drill Ø 0.50mm - 3.00mm
Article No. Description D Flute dia. (mm) D Flute dia. (inch) d Shank dia. (mm) I1 Flute Length (mm) OAL (mm)
3720-000100 GD12-050-3.0-060-C 0.50 0.0197 3.0 6.00 38
3720-000101 GD12-055-3.0-070-C 0.55 0.0217 3.0 7.00 38
3720-000102 GD12-060-3.0-070-C 0.60 0.0236 3.0 7.00 38
3720-000103 GD12-065-3.0-070-C 0.65 0.0256 3.0 7.00 38
3720-000104 GD12-070-3.0-095-C 0.70 0.0276 3.0 9.50 38
3720-000105 GD12-075-3.0-095-C 0.75 0.0295 3.0 9.50 38
3720-000106 GD12-080-3.0-095-C 0.80 0.0315 3.0 9.50 38
3720-000107 GD12-085-3.0-095-C 0.85 0.0335 3.0 9.50 38
3720-000108 GD12-090-3.0-095-C 0.90 0.0354 3.0 9.50 38
3720-000109 GD12-095-3.0-095-C 0.95 0.0374 3.0 9.50 38
3720-000110 GD12-100-3.0-095-C 1.00 0.0394 3.0 9.50 38
3720-000111 GD12-105-3.0-105-C 1.05 0.0413 3.0 10.50 38
3720-000112 GD12-110-3.0-105-C 1.10 0.0433 3.0 10.50 38
3720-000113 GD12-115-3.0-105-C 1.15 0.0453 3.0 10.50 38
3720-000114 GD12-120-3.0-105-C 1.20 0.0472 3.0 10.50 38
3720-000115 GD12-125-3.0-105-C 1.25 0.0492 3.0 10.50 38
3720-000116 GD12-130-3.0-105-C 1.30 0.0512 3.0 10.50 38
3720-000117 GD12-135-3.0-105-C 1.35 0.0531 3.0 10.50 38
3720-000118 GD12-140-3.0-105-C 1.40 0.0551 3.0 10.50 38
3720-000119 GD12-145-3.0-105-C 1.45 0.0571 3.0 10.50 38
3720-000120 GD12-150-3.0-105-C 1.50 0.0591 3.0 10.50 38
3720-000121 GD12-160-3.0-120-C 1.60 0.0630 3.0 12.00 38
3720-000122 GD12-170-3.0-120-C 1.70 0.0669 3.0 12.00 38
3720-000123 GD12-180-3.0-120-C 1.80 0.0709 3.0 12.00 38
3720-000124 GD12-190-3.0-120-C 1.90 0.0748 3.0 12.00 38
3720-000125 GD12-200-3.0-120-C 2.00 0.0787 3.0 12.00 38
3720-000126 GD12-210-3.0-140-C 2.10 0.0827 3.0 14.00 38
3720-000127 GD12-220-3.0-140-C 2.20 0.0866 3.0 14.00 38
3720-000128 GD12-230-3.0-140-C 2.30 0.0906 3.0 14.00 38
3720-000129 GD12-240-3.0-140-C 2.40 0.0945 3.0 14.00 38
3720-000130 GD12-250-3.0-140-C 2.50 0.0984 3.0 14.00 38
3720-000131 GD12-260-3.0-160-C 2.60 0.1024 3.0 16.00 38
3720-000132 GD12-270-3.0-160-C 2.70 0.1063 3.0 16.00 38
3720-000133 GD12-280-3.0-160-C 2.80 0.1102 3.0 16.00 38
3720-000134 GD12-290-3.0-160-C 2.90 0.1142 3.0 16.00 38
3720-000135 GD12-300-3.0-160-C 3.00 0.1181 3.0 16.00 38

Micro Drill Holders

GenSwiss HyperAccurate Micro Drill Holders.
A new standard in holding micro drills in CNC Swiss Machines and Precision Lathes.

Take the NEXT STEP in precision micro drilling performance to meet today’s ever changing demands for high performance, tight tolerance micro parts production.



  • Locking flat prevents damage to sleeve shank and provides
    orientation for use with micro boring bars.
  • Precision manufactured from hard material for longevity
  • Precision nut design retains hyper accurate TIR
  • The BEST solution for holding micro drills

Precision Holders

Part No. Collet Type D1 Shank (inch) L1 Shank (mm)
CS-CHK-254-121 CHK 1.00in 121mm
CS-CHK-127-026 CHK .500in 26mm
CS-CHK-190-076 CHK .750in 76mm



Collets

Part No. Size
CC-CHK-1.0 1.0mm
CC-CHK-1.5 1.5mm
CC-CHK-2.0 2.0mm
CC-CHK-2.5 2.5mm
CC-CHK-3.0 3.0mm



Clamping Nuts

Part No. Descript.
1017-000100 CHK Nut



Wrenches

Part No. Descript.
1035-000114 CHK Wrench

Ti-Loc®

Ti-Loc® Micro Drill & End Mill Extensions

GenSwiss's Ti-Loc® SwissClamp System is a taper-integrated small tooling system designed to work with virtually any collet or tool holder that employs the dual angle ER collet system (DIN6499)

• Reduces Tolerance “Stacking” for low TIR (<.0002")
• Directly Mounts to ANY ER Taper Live or Static Tool Position
• Extends the Reach of Micro-Endmills and Small Shank Rotary Tools
• Enables QUICK CHANGE of tooling
• Coolant Thru Capability in ER16 Sizes

Click HERE for more info...

GenSwiss 2019 Catalog

Utilis 2020 Catalog

GenSwiss REACH Compliance Declaration
